500W FS PLAT HT PLG LH PWR SPLY KT 5963868

SKU
5963868
main product photo
CA$564.00
Only 4 left
HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit





buy now pay later
Category: Power Supplies
  • Primary Information
    Product Description: HPE - power supply - hot-plug / redundant - 500 Watt - 563 VA
    Device Type: Power supply - hot-plug / redundant - plug-in module
    Specification Compliance: Flex Slot
    80 PLUS Certification: 80 PLUS Platinum
    Weight: 32.1 oz
    Input Voltage: AC 100-240 V
    Power Capacity: 500 Watt / 563 VA
    Input Connectors: Power IEC 60320 C14
    Dimensions (WxDxH): 2.7 in x 8.9 in x 1.6 in
    Designed For: Nimble Storage dHCI Medium Solution with HPE ProLiant DL325 Gen10, Small Solution with HPE ProLiant DL360 Gen10; ProLiant DL20 Gen10, DL325 Gen10, DL325 Gen11, DL345 Gen10, DL345 Gen11, DL360 Gen10, DL365 Gen10, DL385 Gen10, DX360 Gen10, DX385 Gen10, ML30 Gen10; SimpliVity 325 Gen10
  • General
    Device Type: Power supply - hot-plug / redundant - plug-in module
    Specification Compliance: Flex Slot
  • Power Device
    Input Voltage: AC 100-240 V
    Frequency Required: 50 - 60 Hz
    Input Connectors: Power IEC 60320 C14
    Power Capacity: 500 Watt / 563 VA
    Efficiency: 94%
    80 PLUS Certification: 80 PLUS Platinum
  • Miscellaneous
    Compliant Standards: Low halogen, UL, cUL, KCC, BSMI, CCC, TUV, C-Tick, CISPR Class A, WEEE
  • Environmental Parameters
    Min Operating Temperature: 41 °F
    Max Operating Temperature: 131 °F
    Humidity Range Operating: 5 - 95% (non-condensing)
  • Dimensions & Weight
    Width: 2.7 in
    Depth: 8.9 in
    Height: 1.6 in
    Weight: 32.1 oz
  • Dimensions & Weight (Shipping)
    Shipping Width: 7.5 in
    Shipping Depth: 14.8 in
    Shipping Height: 5.8 in
    Shipping Weight: 3.51 lbs
  • Compatibility Information
    Designed For: HPE Nimble Storage dHCI Large Solution with HPE ProLiant DL380 Gen10 (500 Watt), Medium Solution with HPE ProLiant DL325 Gen10 Plus (500 Watt), Medium Solution with HPE ProLiant DL360 Gen10 (500 Watt), Small Solution with HPE ProLiant DL360 Gen10 (500 Watt) ¦ HPE ProLiant DL160 Gen10 SMB, DL20 Gen10 Plus (500 Watt), DL20 Gen10 Plus Base (500 Watt), DL20 Gen10 Plus Entry (500 Watt), DL20 Gen10 Plus High Performance (500 Watt), DL20 Gen10 Plus Performance (500 Watt), DL325 Gen10 Plus All-NVMe Flash Node for Qumulo (500 Watt), DL325 Gen10 Plus All-NVMe Flash Node for Software Defined Storage (500 Watt), DL325 Gen10 Plus for Weka BAse Tracking (500 Watt), DL325 Gen10 Plus for Weka Expansion Tracking (500 Watt), DL325 Gen10 Plus V2 (500 Watt), DL325 Gen10 Plus V2 Base (500 Watt), DL325 Gen10 Plus V2 for Weka Base Tracking (500 Watt), DL325 Gen10 Plus V2 Performance (500 Watt), DL325 Gen11, DL345 Gen10 Plus (500 Watt), DL345 Gen10 Plus Base (500 Watt), DL345 Gen10 Plus Entry (500 Watt), DL345 Gen11, DL360 Gen10 All Flash Server for Weka (500 Watt), DL360 Gen10 Compute Server for Cohesity DataPlatform (500 Watt), DL360 Gen10 Performance for Cohesity DataPlatform (500 Watt), DL360 Gen10 Plus (500 Watt), DL360 Gen10 Plus All-NVMe Server for Software Defined Storage (500 Watt), DL360 Gen10 Plus for Weka Base Tracking (500 Watt), DL360 Gen10 Plus Network Choice (500 Watt), DL365 Gen10 Plus (500 Watt), DL380 Gen10 for SAP HANA Compute Block (500 Watt), DL380 Gen10 Hybrid Server for Datera (500 Watt), DL380 Gen10 Network Choice for CTERA (500 Watt), DL380 Gen10 Server for CTERA (500 Watt), DL385 Gen10 Plus V2 Base (500 Watt), DL560 Gen10 for SAP HANA Compute Block (500 Watt), DX360 Gen10 Plus (500 Watt), DX385 Gen10 Plus (500 Watt), DX385 Gen10 Plus Network Choice (500 Watt), ML30 Gen10 Plus (500 Watt), ML30 Gen10 Plus Entry (500 Watt), ML30 Gen10 Plus Performance (500 Watt) ¦ HPE SimpliVity 325 Gen10 Plus V2 Node (500 Watt)
  • Special Feature
    COO: Inquire
    TAA compliance: Inquire
  • UNSPSC Code
    UNSPSC Code: 39121004
More Information
BRANDS HEWLETT PACKARD ENTERPRISE
UNSPSC 39121004
Part# HPE-865408-B21
MFG Part# 865408-B21
UPC 190017072661
Device Type Power supply - hot-plug / redundant - plug-in module
80 PLUS Certification 80 PLUS Platinum
Efficiency 94%
