ASUS NUC 14 ESSENTIAL BAREBONE INTEL N97 SUPPORTS UP TO 16GB W/O OS, W11 8192603
SKU
8192603
CA$248.57
90AR00M2-M000V0 ASUS NUC 14 Essential - NUC14MNK97 - Barebone Kit - Intel Processor N97 - W/O RAM; supports 1 x SO-DIMM DDR5-4800MHz memory slot (up to 16GB 1) - W/O Storage; supports (1) internal storage drive:1 x M.2 2280/2242 NVMe PCIe G3x4 or SATA SSD - Integrated - Intel UHD Graphics - 1 x Realtek RTL8125BG-CG (2.5 GbE) - Intel Wi-Fi 6E AX211 (Gig+), 2x2 - BT 5.3 - W/O OS; supports Windows 11 - 65W - Black - 3-year warranty
Category: Desktops
- Primary Information
System Type: Personal Computer Model: RNUC14MNK970000U Cabinet Form Factor: Desktop Processor / Generation: Intel 14th Generation Processor / Type: N-series Processor / Manufacturer: Intel Multi-Core Technology: Dual-Core Cache Memory Installed Size: 6 MB Max Turbo Frequency: 3.6 GHz Processor / Number: N97 Processor / Installed Qty: 1 Cache Memory Installed Size: 6 MB RAM / Technology: DDR5 RAM / Total Installed Size: None GB RAM / Memory Speed: 4800 MHz RAM Form Factor: SODIMM RAM / Max Supported Size: 16 GB Storage Controller Type: M.2; PCIe 3.0x4 NVMe Hard Drive Capacity / SSD: None GB Storage Controller Type: PCIe 3.0x4 NVMe; M.2 Data Link Protocol: Wi-Fi, Bluetooth 5.3 Network Controller: Intel Wi-Fi 6E AX211 Graphics Controller: Intel UHD Graphic Operating System: None Power / Device Type: USB Charger Power / Provided (W): 65 Watt Interfaces & Connections: 1 x USB 3.2 Gen2 Type-C (with DP1.4 | 5V/3A, 10Gbps), 2 x USB 3.2 Gen2 Type-A (5V/0.9A, 10Gbps), 1 x USB 2.0 Type-A (5V/0.5A, 480Mbps), 1 x HDMI 2.1 (with TMDS, up to 4K@60Hz) , 1 x DisplayPort 1.4, 1 x Realtek 2.5G LAN (RJ45) , 1 x DC-in, Front I/O Ports: 1 x USB 3.2 Gen2 Type-C (5V/3A, 10Gbps), 2 x USB 3.2 Gen2 Type-A (5V/0.9A, 10Gbps), 1 x 3.5mm Audio Jack (Headset), Rear I/O Ports: 1 x USB 3.2 Gen2 Type-C (with DP1.4 | 5V/3A, 10Gbps), 2 x USB 3.2 Gen2 Type-A (5V/0.9A, 10Gbps), 1 x USB 2.0 Type-A (5V/0.5A, 480Mbps), 1 x HDMI 2.1 (with TMDS, up to 4K@60Hz) , 1 x DisplayPort 1.4, 1 x Realtek 2.5G LAN (RJ45) , 1 x DC-in, Expansion Slots Total (Free): 1 x Kensington Lock Slot Width: 5.31 Inch Depth: 4.53 Inch Height: 1.42 Inch Weight: 2.05 lbs. Enclosure Color: Black Service & Support Type: 3-year warranty Security Devices: TPM 2.0 (Intel PTT) - Memory
Cache Memory Type: Smart Cache RAM / Technology: DDR5 RAM / Total Installed Size: None GB RAM / Memory Speed: 4800 MHz RAM Form Factor: SODIMM RAM / Max Supported Size: 16 GB - Processor
Processor / Generation: Intel 14th Generation Processor / Type: N-series Processor / Manufacturer: Intel Multi-Core Technology: Dual-Core Max Turbo Frequency: 3.6 GHz Processor / Number: N97 Processor / Installed Qty: 1 Cache Memory Type: Smart Cache Cache Memory Installed Size: 6 MB - Storage
Hard Drive Capacity / SSD: None GB Storage Controller Type: M.2; PCIe 3.0x4 NVMe - Expansion
Interfaces & Connections: 1 x USB 3.2 Gen2 Type-C (with DP1.4 | 5V/3A, 10Gbps), 2 x USB 3.2 Gen2 Type-A (5V/0.9A, 10Gbps), 1 x USB 2.0 Type-A (5V/0.5A, 480Mbps), 1 x HDMI 2.1 (with TMDS, up to 4K@60Hz) , 1 x DisplayPort 1.4, 1 x Realtek 2.5G LAN (RJ45) , 1 x DC-in, Expansion Slots Total (Free): 1 x Kensington Lock Slot Front I/O Ports: 1 x USB 3.2 Gen2 Type-C (5V/3A, 10Gbps), 2 x USB 3.2 Gen2 Type-A (5V/0.9A, 10Gbps), 1 x 3.5mm Audio Jack (Headset), Rear I/O Ports: 1 x USB 3.2 Gen2 Type-C (with DP1.4 | 5V/3A, 10Gbps), 2 x USB 3.2 Gen2 Type-A (5V/0.9A, 10Gbps), 1 x USB 2.0 Type-A (5V/0.5A, 480Mbps), 1 x HDMI 2.1 (with TMDS, up to 4K@60Hz) , 1 x DisplayPort 1.4, 1 x Realtek 2.5G LAN (RJ45) , 1 x DC-in, - Networking
Data Link Protocol: Wi-Fi, Bluetooth 5.3 Network Controller: Intel Wi-Fi 6E AX211 - Power
Power / Device Type: USB Charger Power / Provided (W): 65 Watt - Special Feature
Security Devices: TPM 2.0 (Intel PTT) COO: Inquire TAA compliance: Inquire - Video
Graphics Controller: Intel UHD Graphic - Dimensions&Miscellaneous
Enclosure Color: Black Width: 5.31 Inch Depth: 4.53 Inch Height: 1.42 Inch Weight: 2.05 lbs. - UNSPSC Code
UNSPSC Code: 43211508
| BRANDS | ASUS |
|---|---|
| UNSPSC | 43211508 |
| Part# | ASU-RNUC14MNK970000U |
| MFG Part# | RNUC14MNK970000U |
| UPC | 197105788176 |
| RAM Form Factor | SODIMM |
| RAM / Total Installed Size | None GB |
| Cache Memory Installed Size | 6 MB |
| Processor / Installed Qty | 1 |
| Multi-Core Technology | Dual-Core |
| Processor / Number | N97 |
| Processor / Manufacturer | Intel |
| RAM / Memory Speed | 4800 MHz |
| Hard Drive Capacity / SSD | None GB |
| Storage Controller Type | M.2, PCIe 3.0x4 NVMe |
| RAM / Technology | DDR5 |
| Cache Memory Type | Smart Cache |
| Max Turbo Frequency | 3.6 GHz |
| Processor / Type | N-series |
| Cabinet Form Factor | Desktop |
| Data Link Protocol | Bluetooth 5.3, Wi-Fi |
| Graphics Controller | Intel UHD Graphic |
| Power / Device Type | USB Charger |
| Operating System | None |
| System Type | Personal Computer |
| Network Controller | Intel Wi-Fi 6E AX211 |
| Processor / Generation | Intel 14th Generation |
