CBS220 SMART 48-PORT GE, 4X1G SFP 6767576
SKU
6767576
Category: Hubs & Switches
- Primary Information
Product Description: Cisco Business 220 Series CBS220-48T-4G - switch - 52 ports - smart - rack-mountable Device Type: Switch - 52 ports - smart Enclosure Type: Rack-mountable Subtype: Gigabit Ethernet Ports: 48 x 10/100/1000 + 4 x Gigabit SFP (uplink) Performance: Forwarding performance (64-byte packet size): 74.38 Mpps ¦ Switching capacity: 104 Gbps Capacity: MSTP instances: 16 ¦ VLANs supported: 256 ¦ ACL rules: 512 ¦ Buffer capacity (MB): 12 MAC Address Table Size: 8192 entries Jumbo Frame Support: 9216 bytes Routing Protocol: IGMPv2, IGMP, IGMPv3, MLDv2, MLD, MSTP, RSTP, STP Remote Management Protocol: SNMP 1, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, SSH-2, CLI, SCP, ICMP, DHCP, RSTP, TACACS+, RADIUS Features: BOOTP support, VLAN support, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, MAC address filtering, Broadcast Storm Control, Multicast Storm Control, ACL support, QoS, Cable Diagnostics Function, LACP support, LLDP support, Port Security, DHCP client, Energy Efficient Ethernet, MIB, dual firmware images, NDP, GVRP, 802.1x authentication, ToS, DSCP support, 1 fan, VLAN management, LLDP-MED, Guest VLAN, UDP, STP loop guard, WRR, HOL Blocking Prevention, loopback detection, Telnet server, Unknown Storm Control, BPDU Guard, CDP, DAD, TCP support, auto voice VLAN, Auto MDIX Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3az Power: AC 100-240 V (50/60 Hz) Dimensions (WxDxH): 17.3 in x 10.1 in x 1.7 in Weight: 7.01 lbs Localization: Colombia, Canada, Chile, Mexico, Latin America, United States Manufacturer Warranty: 3-year warranty - General
Device Type: Switch - 52 ports - smart Enclosure Type: Rack-mountable Subtype: Gigabit Ethernet Ports: 48 x 10/100/1000 + 4 x Gigabit SFP (uplink) Performance: Forwarding performance (64-byte packet size): 74.38 Mpps ¦ Switching capacity: 104 Gbps Capacity: MSTP instances: 16 ¦ VLANs supported: 256 ¦ ACL rules: 512 ¦ Buffer capacity (MB): 12 MAC Address Table Size: 8192 entries Jumbo Frame Support: 9216 bytes Routing Protocol: IGMPv2, IGMP, IGMPv3, MLDv2, MLD, MSTP, RSTP, STP Remote Management Protocol: SNMP 1, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, SSH-2, CLI, SCP, ICMP, DHCP, RSTP, TACACS+, RADIUS Encryption Algorithm: SSL Authentication Method: Secure Shell (SSH), RADIUS, TACACS, TACACS+, Secure Shell v.2 (SSH2) Features: BOOTP support, VLAN support, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, MAC address filtering, Broadcast Storm Control, Multicast Storm Control, ACL support, QoS, Cable Diagnostics Function, LACP support, LLDP support, Port Security, DHCP client, Energy Efficient Ethernet, MIB, dual firmware images, NDP, GVRP, 802.1x authentication, ToS, DSCP support, 1 fan, VLAN management, LLDP-MED, Guest VLAN, UDP, STP loop guard, WRR, HOL Blocking Prevention, loopback detection, Telnet server, Unknown Storm Control, BPDU Guard, CDP, DAD, TCP support, auto voice VLAN, Auto MDIX Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3az RAM: 256 MB Flash Memory: 64 MB Status Indicators: System, link/activity/speed - Expansion / Connectivity
Interfaces: 48 x 10/100/1000 Base-T RJ-45 ¦ 4 x 1000Base-X SFP uplink - Power
Power Device: Internal power supply Voltage Required: AC 100-240 V (50/60 Hz) Power Consumption Operational: 36.5 Watt - Miscellaneous
Rack Mounting Kit: Included MTBF: 727,181 hours Compliant Standards: C-Tick, UL 60950, CSA 22.2, FCC CFR47 Part 15 A Localization: Colombia, Canada, Chile, Mexico, Latin America, United States - Dimensions & Weight
Width: 17.3 in Depth: 10.1 in Height: 1.7 in Weight: 7.01 lbs - Manufacturer Warranty
Service & Support: Limited warranty - replacement - 3 years - response time: next business day - Environmental Parameters
Min Operating Temperature: 32 °F Max Operating Temperature: 122 °F Humidity Range Operating: 10 - 90% (non-condensing) Min Storage Temperature: -4 °F Max Storage Temperature: 158 °F Humidity Range Storage: 10 - 90% (non-condensing) - Special Feature
COO: Inquire TAA compliance: Inquire - UNSPSC Code
UNSPSC Code: 43222612
| BRANDS | CISCO SYSTEMS |
|---|---|
| UNSPSC | 43222612 |
| Part# | CSC-CBS220-48T-4G-NA |
| MFG Part# | CBS220-48T-4G-NA |
| UPC | 889728345248 |
| Device Type | Switch - 52 ports - smart |
| Enclosure Type | Rack-mountable |
| Remote Management Protocol | CLI, DHCP, HTTP, HTTPS, ICMP, RADIUS, RMON, RSTP, SCP, SNMP 1, SNMP 2c, SNMP 3, SSH, SSH-2, TACACS+, Telnet, TFTP |
| Encryption Algorithm | SSL |
