EATON BATTERY (2-HIGH) 9355 15 KVA WITH 32- 5413804
SKU
5413804
CA$43,175.65
Power array - External - Online - AC 220 V - 1 x management - RS-232 - 9 pin D-Sub (DB-9) - Black
Category: Others Devices
- Primary Information
Product Description: Eaton 9355 - power array - 15000 VA Device Type: Power array - external Weight: 372.58 lbs Input Wiring: 3-phase Input Voltage: AC 220 V Output Voltage: AC 220 V Power Capacity: 15000 VA Battery: Lead acid - 9 Ah Battery Form Factor: Internal Batteries Qty: 32 (installed) / 32 (supported) Run Time (Up To): 4 min at full load Networking: RS-232 Color: Black Dimensions (WxDxH): 12.8 in x 33.5 in x 32.2 in - General
Device Type: Power array - external Battery Enclosure Type: Internal Color: Black - Power Device
UPS Technology: On-line Input Voltage: AC 220 V Frequency Provided: 50/60 Hz Input Voltage Margin: + 10% / - 15% Input Wiring: 3-phase Frequency Required: 45 - 65 Hz Output Voltage: AC 220 V 50/60 Hz Power Capacity: 15000 VA - Battery
Quantity: 32 (installed) / 32 (supported) Technology: Lead acid Capacity: 9 Ah Run Time (Up To): 4 min at full load - Networking
Remote Management Interface: RS-232 - Expansion / Connectivity
Interfaces: 1 x management (RS-232) - 9 pin D-Sub (DB-9) Expansion Slots: 2 X-Slot - Miscellaneous
Features: Audible alarm, LCD display, LED display Compliant Standards: UL, ISO 9001, cUL, UL 1778, IEC 60950, ISO 14001, EN 50091-2, IEC 62040-1-1 - Software / System Requirements
Software Included: Drivers & Utilities - Environmental Parameters
Min Operating Temperature: 50 °F Max Operating Temperature: 104 °F Humidity Range Operating: 0 - 95% Sound Emission: 56 dBA - Dimensions & Weight
Width: 12.8 in Depth: 33.5 in Height: 32.2 in Weight: 372.58 lbs - Special Feature
COO: Inquire TAA compliance: Inquire - UNSPSC Code
UNSPSC Code: 39121011
| BRANDS | EATON INDUSTRIES |
|---|---|
| UNSPSC | 39121011 |
| Part# | POW-KA1511200000010 |
| MFG Part# | KA1511200000010 |
| UPC | 743172018601 |
| Device Type | Power array - external |
| UPS Technology | On-line |
| Color | Black |
