EATON UPS SINGLE FEED INTERNAL BATT 93E 30 KV 5383159
SKU
5383159
CA$32,201.00
Eaton 93E - UPS - Tower - Double Conversion - 208/220 VAC - 24KW - 30000VA
Category: UPS
- Primary Information
Product Description: Eaton 93E - UPS - 24 kW - 30000 VA - TAA Compliant Device Type: UPS - external Weight: 1049.39 lbs Input Voltage: AC 208/220 V Output Voltage: AC 208/220 V Power Capacity: 24 kW / 30000 VA Input Connectors: Hardwire Output connectors: 1 x hardwire Battery: Lead acid - 9 Ah Battery Form Factor: Internal Run Time (Up To): 12 min at full load Networking: Ethernet 10/100, RS-232 Remote Management Protocol: SNMP, Telnet, HTTP, SSH Included Accessories: Network Card-MS Color: Black TAA Compliant: TAA Compliant Dimensions (WxDxH): 20.9 in x 31.5 in x 53.5 in Manufacturer Warranty: 1-year warranty - General
Device Type: UPS - external Battery Enclosure Type: Internal Color: Black - Power Device
UPS Technology: On-line Input Voltage: AC 208/220 V Frequency Provided: 50/60 Hz Input Voltage Margin: + 10% / - 15% Frequency Required: 50/60 Hz Input Connectors: Hardwire Power Output Connectors Details: 1 x hardwire Output Voltage: AC 208/220 V 50/60 Hz Power Capacity: 24 kW / 30000 VA Efficiency: 98% - Battery
Technology: Lead acid Capacity: 9 Ah Run Time (Up To): 12 min at full load ¦ 30 min at half load Features: Maintenance free, sealed - Networking
Remote Management Interface: Ethernet 10/100, RS-232 Remote Management Protocol: SNMP, Telnet, HTTP, SSH - Expansion / Connectivity
Interfaces: 1 x management (RS-232) - 9 pin D-Sub (DB-9) Expansion Slots: 2 (total) / 2 (free) x expansion slot - Miscellaneous
Included Accessories: Network Card-MS Features: Advance Battery Management (ABM), audible alarm, LCD display, overload protection, blue LED lighting, Remote Emergency Power Off (REPO) Compliant Standards: UL, CISPR 24, cUL, EN55022, ICES-003, IEC 61000-4-5, UL 1778, VCCI Class A ITE, EN55024, UL 60950, CISPR 22, FCC Part 15 B, IEC 62040-2, WEEE, ISO 9001:2000, ISO 14001:1996 TAA Compliant: Yes - Software / System Requirements
Software Included: Eaton Intelligent Power Software Suite - Manufacturer Warranty
Service & Support: Limited warranty - parts and labor - 1 year - Environmental Parameters
Min Operating Temperature: 32 °F Max Operating Temperature: 86 °F Humidity Range Operating: 5 - 95% (non-condensing) Sound Emission: 65 dBA - Dimensions & Weight
Width: 20.9 in Depth: 31.5 in Height: 53.5 in Weight: 1049.39 lbs - Special Feature
COO: Inquire TAA compliance: Inquire - UNSPSC Code
UNSPSC Code: 39121011
| BRANDS | EATON INDUSTRIES |
|---|---|
| UNSPSC | 39121011 |
| Part# | POW-9EA03GG05021003 |
| MFG Part# | 9EA03GG05021003 |
| Device Type | UPS - external |
| UPS Technology | On-line |
| Color | Black |
| Efficiency | 98% |
| Remote Management Protocol | HTTP, SNMP, SSH, Telnet |
