FORTINET FORTIGATE-401F-DC 18 X GE RJ45 PORTS (INCLUDING 1 X MGMT PORT 1 X HA PORT 16 X SWITCH PORTS) 8 X GE SFP SLOTS 8 X 10GE SFP+ SLOTS SPU NP7 AND 8165832
SKU
8165832
CA$20,119.62
FortiGate-401F-DC 18 x GE RJ45 ports (including 1 x MGMT port, 1 X HA port, 16 x switch ports), 8 x GE SFP slots, 8 x 10GE SFP+ slots, SPU NP7 and CP9 hardware accelerated, 960GB onboard SSD storage, dual DC power supplies
Category: Network Devices
- Primary Information
Product Description: Fortinet FortiGate 401F-DC - security appliance - cloud-managed Device Type: Security appliance Form Factor: Front and side to back rack-mountable - 1U Processor: Fortinet FortiASIC CP9/NP7 Hard Drive: 480 GB x 2 Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet Performance: IPS throughput (enterprise traffic mix): 12 Gbps ¦ NGFW throughput (enterprise traffic mix): 10 Gbps ¦ Threat protection throughput (enterprise traffic mix): 9 Gbps ¦ IPv4 firewall throughput (1518-byte UDP): 79.5 Gbps ¦ IPv4 firewall throughput (512-byte UDP): 78.5 Gbps ¦ IPv4 firewall throughput (64-byte UDP): 70 Gbps ¦ IPv6 firewall throughput (1518-byte UDP): 79.5 Gbps ¦ IPv6 firewall throughput (512-byte UDP): 78.5 Gbps ¦ IPv6 firewall throughput (86-byte UDP): 70 Gbps ¦ Firewall latency (64-byte UDP): 4.19 µs ¦ Firewall latency (64-byte UDP, ULL ports): 2.5 µs ¦ Firewall throughput: 105 Mpps ¦ VPN throughput (512-bit IPSec): 55 Gbps ¦ VPN throughput (SSL): 3.6 Gbps ¦ SSL inspection throughput: 8 Gbps ¦ Application control throughput: 28 Gbps ¦ CAPWAP throughput: 65 Gbps Capacity: Concurrent TCP sessions: 7800000 ¦ New TCP sessions per second: 500000 ¦ Firewall policies: 10000 ¦ Gateway to gateway IPSec VPN Tunnels: 2000 ¦ Client to gateway IPSec VPN tunnels: 50000 ¦ Concurrent SSL VPN users: 5000 ¦ SSL inspection CPS: 6000 ¦ SSL inspection concurrent sessions: 800000 ¦ Virtual domains: 10 ¦ Maximum virtual domains: 10 ¦ Number of FortiSwitches: 72 ¦ Number of FortiAP devices: 512 ¦ Number of FortiAP devices (tunnel): 256 ¦ Number of FortiToken devices: 5000 Included Accessories: 2 x 1Gb Ethernet SX SFP transceiver Power: DC 48-60 V Power Redundancy: Yes Dimensions (WxDxH): 17 in x 15 in x 1.7 in Weight: 14.33 lbs - General
Device Type: Security appliance Height (Rack Units): 1U Width: 17 in Depth: 15 in Height: 1.7 in Weight: 14.33 lbs - Processor / Memory / Storage
Processors Installed: Fortinet FortiASIC CP9/NP7 Hard Drive: SSD 480 GB x 2 - Networking
Form Factor: Rack-mountable Airflow Direction: Front and side to back Connectivity Technology: Wired Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet Network / Transport Protocol: IPv4, IPv6, IPSec, UDP/IP, TCP/IP, HTTP, HTTPs Remote Management Protocol: HTTP, HTTPS Cloud-Managed: Yes Performance: IPS throughput (enterprise traffic mix): 12 Gbps ¦ NGFW throughput (enterprise traffic mix): 10 Gbps ¦ Threat protection throughput (enterprise traffic mix): 9 Gbps ¦ IPv4 firewall throughput (1518-byte UDP): 79.5 Gbps ¦ IPv4 firewall throughput (512-byte UDP): 78.5 Gbps ¦ IPv4 firewall throughput (64-byte UDP): 70 Gbps ¦ IPv6 firewall throughput (1518-byte UDP): 79.5 Gbps ¦ IPv6 firewall throughput (512-byte UDP): 78.5 Gbps ¦ IPv6 firewall throughput (86-byte UDP): 70 Gbps ¦ Firewall latency (64-byte UDP): 4.19 µs ¦ Firewall latency (64-byte UDP, ULL ports): 2.5 µs ¦ Firewall throughput: 105 Mpps ¦ VPN throughput (512-bit IPSec): 55 Gbps ¦ VPN throughput (SSL): 3.6 Gbps ¦ SSL inspection throughput: 8 Gbps ¦ Application control throughput: 28 Gbps ¦ CAPWAP throughput: 65 Gbps Capacity: Concurrent TCP sessions: 7800000 ¦ New TCP sessions per second: 500000 ¦ Firewall policies: 10000 ¦ Gateway to gateway IPSec VPN Tunnels: 2000 ¦ Client to gateway IPSec VPN tunnels: 50000 ¦ Concurrent SSL VPN users: 5000 ¦ SSL inspection CPS: 6000 ¦ SSL inspection concurrent sessions: 800000 ¦ Virtual domains: 10 ¦ Maximum virtual domains: 10 ¦ Number of FortiSwitches: 72 ¦ Number of FortiAP devices: 512 ¦ Number of FortiAP devices (tunnel): 256 ¦ Number of FortiToken devices: 5000 Status Indicators: Status, alarm, HA, power Features: Trusted Platform Module (TPM), Zero Trust Network Access (ZTNA), SSL inspection, VPN support, SD-WAN support, CAPWAP support, High Availability, NGFW appliance, AI/ML powered, self-healing network, advanced sandbox detection, Intrusion Prevention System (IPS), anti-malware protection, URL protection, DNS filtering, Data Loss Prevention (DLP), reset button, DDos attack prevention Encryption Algorithm: TLS 1.3, SSL, 256-bit AES, 256-bit SHA - Expansion / Connectivity
Interfaces: 1 x USB - Type A ¦ 1 x console - RJ-45 ¦ 1 x 1000Base-T (management) - RJ-45 ¦ 1 x 1000Base-T (HA) - RJ-45 ¦ 16 x 1000Base-T - RJ-45 ¦ 4 x 1000Base-X/10GBase-X - SFP+ ¦ 4 x 10GBase-X (ultra-low latency) - SFP+ ¦ 8 x 1000Base-X - SFP - Miscellaneous
Included Accessories: 2 x 1Gb Ethernet SX SFP transceiver Compliant Standards: FCC Part 15 A, RCM, VCCI, UL, cUL, CB, USGv6 - Power
Power Device: Internal power supply - hot-plug Max Supported Qty: 2 Power Redundancy: Yes Voltage Required: DC 48-60 V 80 PLUS Certification: 80 PLUS - Software / System Requirements
OS Provided: FortiOS - Environmental Parameters
Min Operating Temperature: 32 °F Max Operating Temperature: 104 °F Humidity Range Operating: 5 - 90% (non-condensing) - Special Feature
COO: Inquire TAA compliance: Inquire - UNSPSC Code
UNSPSC Code: 43222501
| BRANDS | FORTINET |
|---|---|
| UNSPSC | 43222501 |
| Part# | FOR-FG-401F-DC |
| MFG Part# | FG-401F-DC |
| Device Type | Security appliance |
| 80 PLUS Certification | 80 PLUS |
| Connectivity Technology | Wired |
| Form Factor | Rack-mountable |
| Data Link Protocol | 10 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol | HTTP, HTTPS |
| Encryption Algorithm | 256-bit AES, 256-bit SHA, SSL, TLS 1.3 |
