Network Device Type: | Switch |
Model: | 6300F |
Form Factor: | 1U |
Connectivity Technology: | Wired |
Data Transfer Rate: | 50 Gbps |
Networking / Ports Qty: | 31 |
Data Link Protocol: | Gigabit Ethernet |
Processor / Type: | ARM Cortex A72 |
RAM / Total Installed Size: | 8 GB |
Flash Memory / Installed Size: | 32 GB |
Networking Compliant Standards: | 802.1p, 802.1w, 802.1s |
Power / Device Type: | Power Supply |
Media Layer Supported: | Layer 2, Layer 3 |
Power / Installed Qty: | 1 |
Uplink Port: | 4 |
Power / Provided (W): | 950 Watt |
Max Power Consumption: | 67 Watt |
Power / Voltage Required: | 100V-120V/200V-240V |
Features: | Automation and Analytics. Performance and Power. Smarter Segmentation. |
Power Over Ethernet (PoE) Support: | Y |
PoE Power Consumption: | 370 W |
MAC Address Table Size: | 32768 |
Jumbo Frame Support: | Y |
Remote Management Protocol: | CLI; RMON; SNMP |
Routing Protocol: | BGP, OSPF, RIPv2 |
Encryption Algorithm: | MACsec |
Authentication Method: | RADIUS, TACACS+, MD5 |
Interfaces: | 10/100/1000 BaseT PoE+, SFP56, USB-C Console, OOBM, USB Type A Host |
Interfaces: | 10/100/1000 BaseT PoE+, SFP56, USB-C Console, OOBM, USB Type A Host |
Width: | 17.4 Inch |
Depth: | 12.9 Inch |
Height: | 1.73 Inch |
Weight: | 4.95 Kg |
Service & Support Type: | Limited Lifetime Warranty |
Min Operating Temperature: | 0 Celsius |
Max Operating Temperature: | 45 Celsius |
Min Storage Temperature: | -40 Celsius |
Max Storage Temperature: | 70 Celsius |
RoHS: | Y |
COO: | Inquire |
TAA compliance: | Inquire |
UNSPSC Code: | 43222612 |
BRANDS | HEWLETT PACKARD ENTERPRISE |
---|---|
UNSPSC | 43222612 |
Part# | HPE-S0G96A#ABA |
MFG Part# | S0G96A#ABA |
Flash Memory / Installed Size | 32 GB |
Network Device Type | Switch |
RAM / Total Installed Size | 8 GB |
Power / Installed Qty | 1 |
Connectivity Technology | Wired |
Data Transfer Rate | 50 Gbps |
Form Factor | 1U |
Processor / Type | ARM Cortex A72 |
Networking / Ports Qty | 31 |
Data Link Protocol | Gigabit Ethernet |
Power / Device Type | Power Supply |
Remote Management Protocol | CLI, RMON, SNMP |
Encryption Algorithm | MACsec |
