Product Description: | HP Workstation Z2 G9 - tower Core i9 13900K 3 GHz - 128 GB - SSD 512 GB - US |
Type: | Workstation - tower |
Height (Rack Units): | 4U |
Localization: | Language: English / region: United States |
Processor: | 1 x Intel Core i9 (13th Gen) 13900K / 3 GHz (up to 5.8 GHz, (24-core) |
Processor Socket: | LGA1700 Socket |
Processor Main Features: | Intel Turbo Boost Technology |
Cache Memory: | 36 MB L3 cache |
Cache Per Processor: | 36 MB |
RAM: | 128 GB (installed) / 128 GB (max) - DDR5 SDRAM - non-ECC |
Storage Controller: | SATA (SATA 6Gb/s) |
Hard Drive: | SSD 512 GB - PCI Express 4.0 x4 - M.2 2280 - HP Z Turbo Drive, NVM Express (NVMe), triple-level cell (TLC) |
Optical Storage: | No optical drive |
Multi-GPU Configuration: | 1 single GPU card / integrated GPU |
Graphics Controller: | NVIDIA RTX A5000 / Intel UHD Graphics 770 |
Video Memory: | 24 GB GDDR6 SDRAM |
Networking: | 1GbE |
Keyboard: | US |
Power: | (50/60 Hz) |
OS Provided: | Windows 11 Pro |
Software Included: | HP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP BIOS Configuration Utility (free download), HP Driver Packs, HP Image Assistant, HP PC Hardware Diagnostics, HP System Software Manager (free download), HP Sure Click, HP Manageability Integration Kit, HP Sure Admin, HP Client Security Manager Gen6, HP BIOSphere Gen6, HP ZCentral Remote Boost, HP Sure Recover Gen4, HP SureStart Gen7, HP Management Integration Kit for Microsoft System Center Configuration Manager Gen 4, HP Performance Advisor 3.0, HP Sure Sense Gen2, HP Sure Run Gen5 |
Color: | Black |
Dimensions (WxDxH): | 6.7 in x 15.2 in x 14 in |
Weight: | 15.87 lbs |
Environmental Standards: | ENERGY STAR Qualified EPEAT Gold |
Type: | Workstation |
Product Form Factor: | Tower - 4U |
Embedded Security: | Trusted Platform Module (TPM 2.0) Security Chip |
Color: | Black |
Localization: | Language: English / region: United States |
CPU: | Intel Core i9 (13th Gen) 13900K |
Clock Speed: | 3 GHz (P-core) / 2.2 GHz (E-core) |
Max Turbo Speed: | 5.8 GHz (P-core) / 4.3 GHz (E-core) |
Number of Cores: | 24-core |
CPU Qty: | 1 |
Max CPU Qty: | 1 |
L2 cache: | 32 MB |
CPU Upgradability: | Upgradable |
Processor Main Features: | Intel Turbo Boost Technology |
CPU Socket: | LGA1700 Socket |
Chipset Type: | Intel W680 |
Installed Size: | L3 cache - 36 MB |
Cache Per Processor: | 36 MB |
Installed Size: | 128 GB (installed) / 128 GB (max) |
Technology: | DDR5 SDRAM - non-ECC |
Effective Memory Speed: | 4800 MHz |
Rated Memory Speed: | 4800 MHz |
Form Factor: | DIMM 288-pin |
Slots: | 4 (total) / 0 (empty) |
Configuration Features: | 4 x 32 GB |
Type: | SSD - M.2 2280 |
Capacity: | 1 x 512 GB |
Interface Type: | PCI Express 4.0 x4 |
Features: | HP Z Turbo Drive, NVM Express (NVMe), triple-level cell (TLC) |
Type: | 1 x SATA |
Controller Interface Type: | SATA 6Gb/s |
Channel Qty: | 4 |
RAID Level: | RAID 0, RAID 1 |
Type: | No optical drive |
Monitor Type: | None. |
Multi-GPU Configuration: | 1 single GPU card / integrated GPU |
Graphics Processor: | NVIDIA RTX A5000 / Intel UHD Graphics 770 |
Video Memory: | 24 GB GDDR6 SDRAM |
Bandwidth: | 768 GBps |
Max Monitors Supported: | 4 |
Compliant Standards: | High Definition Audio |
Type: | Mouse, keyboard |
Keyboard Name: | HP 125 |
Localization & Layout: | US |
Mouse Name: | HP 125 |
Ethernet Controller: | Intel I219-LM |
Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet |
Features: | Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support, Intel Active Management Technology (AMT) 15 |
Compliant Standards: | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1as, IEEE 802.3az |
Bays: | 1 (total) / 1 (free) x external 5.25" ¦ 1 (total) / 1 (free) x external 5.25" Slim Line ¦ 2 (total) / 2 (free) x internal 3.5" ¦ 1 (total) / 1 (free) x internal 2.5" |
Slots: | 1 (total) / 0 (free) x PCIe 5.0 x16 - full-length, full-height (x16 mode) ¦ 1 (total) / 1 (free) x PCIe 3.0 x4 - full-length, full-height (x4 mode) ¦ 1 (total) / 1 (free) x PCIe 3.0 x4 - full-length, full-height (x16 mode) ¦ 1 (total) / 1 (free) x PCIe 3.0 x1 - full-length, full-height (x4 mode) ¦ 3 (total) / 2 (free) x M.2 Card - 2280 (PCIe 4.0 x4 mode) ¦ 1 (total) / 1 (free) x M.2 Card - 2230 (PCIe 3.0 x1 mode (for wireless module)) |
Interfaces: | 1 x headphones/microphone (1 in front) (CTIA and OMTP headset support) ¦ 6 x USB 3.2 Gen 2 (4 front, 2 rear) (one of them is charging) ¦ 1 x audio line-in (1 rear) ¦ 1 x audio line-out (1 rear) ¦ 2 x DisplayPort 1.4 (2 rear) ¦ 3 x USB 2.0 (3 rear) ¦ 1 x USB 3.2 Gen 1 (1 rear) ¦ 1 x LAN (Gigabit Ethernet) (1 rear) ¦ 4 x DisplayPort 1.4 |
Theft/Intrusion Protection: | Security lock slot (cable lock sold separately) |
Security Slot Type: | Kensington security slot |
Compliant Standards: | RoHS, FIPS 140-2, WEEE, Energy-Related Products (ErP) Lot 6, CECP, SEPA, low halogen |
Device Type: | Power supply |
Voltage Required: | AC 90-269 V (50/60 Hz) |
Power Provided: | 700 Watt |
Efficiency: | 92% |
Power Factor Correction: | Yes (active) |
OS Provided: | Windows 11 Pro English |
Software: | HP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP BIOS Configuration Utility (free download), HP Driver Packs, HP Image Assistant, HP PC Hardware Diagnostics, HP System Software Manager (free download), HP Sure Click, HP Manageability Integration Kit, HP Sure Admin, HP Client Security Manager Gen6, HP BIOSphere Gen6, HP ZCentral Remote Boost, HP Sure Recover Gen4, HP SureStart Gen7, HP Management Integration Kit for Microsoft System Center Configuration Manager Gen 4, HP Performance Advisor 3.0, HP Sure Sense Gen2, HP Sure Run Gen5 |
EPEAT Compliant: | EPEAT Gold |
ENERGY STAR Certified: | Yes |
Width: | 6.7 in |
Depth: | 15.2 in |
Height: | 14 in |
Weight: | 15.87 lbs |
Shipping Width: | 11.6 in |
Shipping Depth: | 19.3 in |
Shipping Height: | 20.4 in |
Min Operating Temperature: | 41 °F |
Max Operating Temperature: | 95 °F |
Humidity Range Operating: | 10 - 85% RH (non-condensing) |
COO: | Inquire |
TAA compliance: | Inquire |
UNSPSC Code: | 43201503 |
BRANDS | HP |
---|---|
UNSPSC | 43201503 |
Part# | HPI-92J65UA#ABA |
MFG Part# | 92J65UA#ABA |
Device Type | Power supply |
Form Factor | DIMM 288-pin |
RAID Level | RAID 0, RAID 1 |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
Graphics Controller | NVIDIA RTX A5000 / Intel UHD Graphics 770 |
Type | keyboard, Mouse |
Color | Black |
Efficiency | 92% |
Max Monitors Supported | 4 |
Interface Type | PCI Express 4.0 x4 |
