MSA 2052 SAS DC LFF TAA STORAGE 6664560
SKU
6664560
Category: Storage Controllers
- Primary Information
Product Description: HPE Modular Smart Array 2052 SAS Dual Controller LFF Storage - solid state / hard drive array - TAA Compliant Device Type: Solid state / hard drive array Enclosure Type: Rack-mountable - 2U Total Array Capacity: 1.6 TB Max Supported Capacity: 960 TB Maximum LUNs: 512 Installed Devices / Modules Qty: 2 (installed) / 12 (max) Supported Drives: SAS-2 Storage Controller: RAID (SAS 6Gb/s) - RAID 1, 5, 6, 10 Storage Controller Quantity: 2 Hard Drive: 2 x 800 GB SSD Mixed-Use OS Required: HP-UX, SuSe Linux, Apple MacOS X, Microsoft Windows, Red Hat Enterprise Linux, HP OpenVMS, Microsoft Windows Server 2012, VMware ESXi 5.x, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2012 R2 with Hyper-V, VMware ESXi 6.x Power: AC 120/230 V - 50/60 Hz Power Redundancy: Yes TAA Compliant: Yes Dimensions (WxDxH): 17.6 in x 22.5 in x 3.5 in Weight: 40.56 lbs Environmental Standards: ENERGY STAR Qualified Manufacturer Warranty: 3-year warranty - General
Device Type: Solid state / hard drive array Enclosure Type: Rack-mountable - 2U - Chassis
Installed Devices / Modules Qty: 2 Supported Devices / Modules Qty: 12 Supported Drives: SAS-2 - Storage
Total Array Capacity: 1.6 TB Max Supported Capacity: 960 TB Maximum LUNs: 512 Storage Capacity Details: Raw 960 TB - Processor
CPU: No CPU - Storage Controller
Type: RAID (iSCSI) Installed Qty: 2 Interface Type: SAS 6Gb/s Data Transfer Rate: 600 MBps Cache / Buffer Size (Max): 8 GB RAID Level: RAID 1, RAID 5, RAID 6, RAID 10 - Storage Controller (2nd)
Installed Qty: 2 - Hard Drive
Type: SSD Capacity: 2 x 800 GB Features: Mixed-Use - Expansion / Connectivity
Expansion Bays: 12 (total) / 10 (free) - 3.5" LFF Interfaces: 4 x Ethernet 10Gb (iSCSI) / 16Gb Fibre Channel ¦ 2 x mini-USB 2.0 (management) ¦ 2 x Ethernet 1000Base-T (management) - RJ-45 ¦ 2 x SAS - System Requirements
OS Required: HP-UX, SuSe Linux, Apple MacOS X, Microsoft Windows, Red Hat Enterprise Linux, HP OpenVMS, Microsoft Windows Server 2012, VMware ESXi 5.x, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2012 R2 with Hyper-V, VMware ESXi 6.x - Miscellaneous
Features: Systems Insight Manager (SIM) Software Included: HPE Advanced Data Services Suite, HPE 3PAR Virtual Copy, HPE MSA Remote Snap Software Compliant Standards: CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN55022, GS, EN 61000-3-3, EN55024, CCC, FCC Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, WEEE, RoHS, CAN/CSA C22.2 No. 60950-1-03, VCCI Class A, KN24, KN22 Class A, CNS 13438 Class A, ICES-003:2004 Class A TAA Compliant: Yes - Environmental Standards
ENERGY STAR Certified: Yes - Power
Power Device: 2 x internal power supply - hot-plug Max Supported Qty: 2 Power Redundancy: Yes Voltage Required: AC 120/230 V - 50/60 Hz Power Consumption Operational: 374 Watt - Dimensions & Weight
Width: 17.6 in Depth: 22.5 in Height: 3.5 in Weight: 40.56 lbs - Manufacturer Warranty
Service & Support: Limited warranty - parts - 3 years - Environmental Parameters
Min Operating Temperature: 41 °F Max Operating Temperature: 104 °F Humidity Range Operating: 10 - 90% (non-condensing) Sound Emission: 55 dBA - Special Feature
COO: Inquire TAA compliance: Inquire - UNSPSC Code
UNSPSC Code: 43201404
| BRANDS | HEWLETT PACKARD ENTERPRISE |
|---|---|
| UNSPSC | 43201404 |
| Part# | HPE-R4Y05A |
| MFG Part# | R4Y05A |
| UPC | 190017454047 |
| Device Type | Solid state / hard drive array |
| Data Transfer Rate | 600 MBps |
| RAID Level | RAID 1, RAID 10, RAID 5, RAID 6 |
| Type | SSD |
| Enclosure Type | Rack-mountable - 2U |
| Interface Type | SAS 6Gb/s |
