Model: | MDNC-2221 |
Display Type: | LED Backlight |
Display Technology: | LED Backlight |
Flat / Curved: | Flat |
Max Resolution: | 1600 x 1200 |
Display Diagonal Size: | 21.3 Inch |
Display / Color Support: | 30-bit Color |
Display / Response Time: | 10 Ms |
Dot Pitch / Pixel Pitch: | 0.27 Mm |
Image Contrast Ratio: | 1400:1 |
Brightness: | Maximum luminance (panel typical):800 cd/m2; DICOM calibrated luminance:500 cd/m2 |
Viewing Angle: | 178/178 |
Image Aspect Ratio: | 4:3 |
Picture Enhancements: | None |
Network Connectivity: | None |
Interfaces: | 1x DVI;1x DisplayPort;1x USB 2.0 upstream (endpoint);2x USB 2.0 downstream |
Video Interfaces: | DisplayPort; DVI |
DisplayPort Qty: | 1 |
VGA Qty: | 1 |
Power Consumption Operational: | 50 Watt |
Power / Voltage Required: | Input rating: 100-240 VAC, 2 A, 50 - 60 Hz; Output rating: 24 VDC, 3.75 A |
Power Consumption Standby: | < 1 W |
Adjustable Display Tilt: | -5 to 25 degree |
Adjustable Display Height: | 100 mm |
Adjustable Display Swivel: | -30 to +30 degree |
Adjustable Display Pivot: | 90 degree |
Stand: | Yes |
VESA Mount Compatible: | 100 x 100 mm |
Width: | Portrait:378;Landscape:491 Mm |
Depth: | Portrait:83;Landscape:83 Mm |
Height: | Portrait:491;Landscape:378 Mm |
Weight: | 6.3 Kg |
Min Operating Temperature: | 0 Celsius |
Max Operating Temperature: | 35 Celsius |
Humidity Range Operating: | 8% to 80% (non-condensing) |
