RARITAN 1PH, 230V AC, 32A (32A RATED); 20 OUTLETS: 16X C13, 4X C19; PLUG: IEC 60309 2P+E 6H 32A (REAR FEED), 7.4KVA; UNIT METERED, 2U HORIZONTAL TRANS 8168524

SKU
8168524
main product photo
CA$4,103.95
1PH, 230V AC, 32A (32A RATED); 20 OUTLETS: 16 x C13, 4 x C19; PLUG: IEC 60309 2P+E 6H 32A (REAR FEED), 7.4KVA; UNIT METERED, 2U HORIZONTAL TRANSFER SWITCH, SECURELOCK READY, LCD DISPLAY, ETHERNET, SERIAL, 2 x USB-A, USB-B AND SENSOR CONNECTIONS





buy now pay later
Category: Power Distribution Units
  • Primary Information
    Product Description: Raritan Intelligent Rack Transfer Switch PX3TS-1469R - power control unit - 5800 VA
    Device Type: Power control unit - rack-mountable
    Rack Size: 2U
    Input Voltage: AC 200-240 V
    Output Voltage: AC 200-240 V
    Power Capacity: 5800 VA
    Input Connectors: 2 x power IEC 60309 32A
    Output connectors: 16 x power IEC 60320 C13 ¦ 4 x power IEC 60320 C19
    Networking: Ethernet, RS-232, USB
    Remote Management Protocol: SNMP
  • General
    Device Type: Power control unit - rack-mountable
    Height (Rack Units): 2U
  • Power Device
    Input Voltage: AC 200-240 V
    Frequency Required: 50/60 Hz
    Input Connectors: 2 x power IEC 60309 32A
    Power Output Connectors Details: 16 x power IEC 60320 C13 ¦ 4 x power IEC 60320 C19
    Output Voltage: AC 200-240 V
    Max Electric Current: 32 A
    Power Capacity: 5800 VA
    Circuit Protection: Fuse
  • Networking
    Remote Management Interface: Ethernet, RS-232, USB
    Remote Management Protocol: SNMP
  • Expansion / Connectivity
    Interfaces: 1 x serial - 9 pin D-Sub (DB-9) ¦ 1 x management - 4 pin USB Type A ¦ 1 x modem - 9 pin D-Sub (DB-9) ¦ 1 x monitoring - RJ-45 ¦ 1 x LAN - RJ-45 ¦ 1 x USB - 4 pin USB Type B ¦ 1 x monitoring - RJ-12 ¦ 1 x USB - 4 pin USB Type A
  • Miscellaneous
    Cables Included: 2 x power cable - external - 10 ft
    Features: Voltage monitoring, amp meter, active power meter, energy meter, power factor meter
    Compliant Standards: UL
  • Environmental Parameters
    Max Operating Temperature: 140 °F
    Humidity Range Operating: 85%
  • Special Feature
    COO: TAIWAN
  • UNSPSC Code
    UNSPSC Code: 39121017
More Information
BRANDS RARITAN
UNSPSC 39121017
Part# RAR-PX3TS-1469R
MFG Part# PX3TS-1469R
Device Type Power control unit - rack-mountable
Circuit Protection Fuse
Remote Management Protocol SNMP
