SUPERMICRO X10DRI-T4+, CSE-826BTS-R920LPBP-1 6762509
SKU
6762509
Category: Servers
- Primary Information
System Type: Server Model: SSG-6028R-E1CR12N Cabinet Form Factor: 2U Processor / Type: Xeon Processor / Manufacturer: Intel Processor / Number: E5-2600 Multi-Core Technology: 22-Core Mainboard / Chipset Type: Intel C612 RAM / Technology: DDR4 RAM Form Factor: DIMM 288-pin RAM / Total Slots Qty: 24 Hot-Swap Bays Qty: 12 Controller Interface Type: SATA 6 Gb/s; SAS 12 Gb/s Graphics Controller: ASPEED AST2400 BMC Power / Voltage Required: 100-240 V, 50-60 Hz, 11-4.5 Amp Interfaces & Connections: LAN 4 RJ45 10GBase-T LAN ports 1 RJ45 Dedicated IPMI LAN port USB 3 USB 3.0 ports (2 rear + 1 Type A) 2 USB 2.0 ports (2 rear) VGA 1 VGA port Serial Port / Header 1 Fast UART 16550 port / 1 Header Width: 17.2 Inch Depth: 3.5 Inch Height: 25.6 Inch Min Operating Temperature: 10 Celsius Max Operating Temperature: 35 Celsius Humidity Range Operating: 8% to 90% (non-condensing) - Special Feature
RoHS: Y COO: Inquire TAA compliance: Inquire - Processor
Processor / Manufacturer: Intel Processor / Type: Xeon Processor / Number: E5-2600 Multi-Core Technology: 22-Core - RAM
RAM / Technology: DDR4 RAM Form Factor: DIMM 288-pin RAM / Total Slots Qty: 24 - Storage
Hot-Swap Bays Qty: 12 - Video
Graphics Controller: ASPEED AST2400 BMC - Power
Power / Voltage Required: 100-240 V, 50-60 Hz, 11-4.5 Amp - Expansion
Interfaces & Connections: LAN 4 RJ45 10GBase-T LAN ports 1 RJ45 Dedicated IPMI LAN port USB 3 USB 3.0 ports (2 rear + 1 Type A) 2 USB 2.0 ports (2 rear) VGA 1 VGA port Serial Port / Header 1 Fast UART 16550 port / 1 Header - Dimensions&Miscellaneous
Width: 17.2 Inch Depth: 3.5 Inch Height: 25.6 Inch - UNSPSC Code
UNSPSC Code: 43211502
| BRANDS | SUPERMICRO COMPUTER |
|---|---|
| UNSPSC | 43211502 |
| Part# | SPM-SSG-6028R-E1CR12N |
| MFG Part# | SSG-6028R-E1CR12N |
| RAM Form Factor | DIMM 288-pin |
| Mainboard / Chipset Type | Intel C612 |
| Multi-Core Technology | 22-Core |
| Processor / Number | E5-2600 |
| Processor / Manufacturer | Intel |
| RAM / Total Slots Qty | 24 |
| RAM / Technology | DDR4 |
| Processor / Type | Xeon |
| Cabinet Form Factor | 2U |
| Graphics Controller | ASPEED AST2400 BMC |
| System Type | Server |
