T8504-R INDUSTRIAL POE SWITCH 6300458
SKU
6300458
CA$1,079.83
AXIS T8504-R Industrial PoE Switch is a 4-port managed industrial PoE++ Gigabit switch. In addition, the switch is equipped with 2 x RJ45 and 2x SFP data ports that allows for extra devices to be connected. The switch uses the same intuitive administrator interface as AXIS T85 PoE Network Switch Series, is ruggedized with a wide temperature range and NEMA TS2 compliant.
Category: Hubs & Switches
- Primary Information
Network Device Type: Switch Model: AXIS T8504-R Industrial PoE Switch Connectivity Technology: Wired Networking Compliant Standards: IEEE 802.1X, 802.1Q, IEEE 802.3at, IEEE 802.3af Power / Device Type: Power Supply Power / Installed Qty: 2 Uplink Port: 2 x RJ45 10Base-T/100Base-TX/1000Base-T Mbps Power / Voltage Required: 48 - 57 V DC Features: 60W per port, 240W power budget; Compliant with High PoE 60W; High availability with Rapid Ring; Dual DC power redundancy; NEMA TS-2 Compliant - Network
Power Over Ethernet (PoE) Support: YES PoE Power Consumption: 240W MAC Address Table Size: 8K Jumbo Frame Support: 9216 Bytes Remote Management Protocol: DHCP; Syslog; SNMP; SSH; HTTP; HTTPS Authentication Method: RADIUS, TACACS+ Interfaces: PoE ports:J45 10Base-T/100Base-TX/1000Base-T Mbps (4x); Data ports/Uplink:RJ45 10Base-T/100Base-TX/1000Base-T Mbps (2x) SFP port (2x); Console: RJ45 (1x) - Interfaces / Ports
Interfaces: PoE ports:J45 10Base-T/100Base-TX/1000Base-T Mbps (4x); Data ports/Uplink:RJ45 10Base-T/100Base-TX/1000Base-T Mbps (2x) SFP port (2x); Console: RJ45 (1x) - Dimensions&Miscellaneous
Enclosure Color: Black Width: 5.3 Inch Depth: 5.1 Inch Height: 2.4 Inch Weight: 0.6 Kg - Service&Support
Service & Support Type: 5-year warranty - Special Feature
Min Operating Temperature: -40 Celsius Max Operating Temperature: 75 Celsius Min Storage Temperature: -40 Celsius Max Storage Temperature: 85 Celsius COO: Inquire TAA compliance: Inquire - UNSPSC Code
UNSPSC Code: 43222612
| BRANDS | AXIS COMMUNICATIONS |
|---|---|
| UNSPSC | 43222612 |
| Part# | ACI-01633-001 |
| MFG Part# | 01633-001 |
| UPC | 7331021066199 |
| Network Device Type | Switch |
| Power / Installed Qty | 2 |
| Connectivity Technology | Wired |
| Power / Device Type | Power Supply |
| Remote Management Protocol | DHCP, HTTP, HTTPS, SNMP, SSH, Syslog |
