TP-LINK OMADA PRO 48-PORT 10G STACKABLE L3 MANAGED AGGREGATION SWITCH WITH 4 100G SLO 8217016
SKU
8217016
CA$22,999.99
Switch - S7500-48XF4C - Wired - 10Gbps - Networking / Ports Qty: 48 - 10 Gigabit Ethernet
Category: Hubs & Switches
- Primary Information
Product Description: TP-Link Omada Pro S7500-48XF4C V1 - switch - 48 ports - managed - rack-mountable Device Type: Switch - 48 ports - L3 - managed - stackable Enclosure Type: Front to back airflow rack-mountable Subtype: 10 Gigabit Ethernet Ports: 48 x 10 Gigabit SFP+ + 4 x 100 Gigabit QSFP28 Performance: Switching capacity: 1760 Gbps ¦ Packet forwarding rate: 600 Mpps ¦ Stacking bandwidth: 800 Gbps ¦ Forwarding bandwidth: 880 Gbps Capacity: Buffer capacity (MB): 10 ¦ Priority queues: 8 ¦ Layer 3 IP interfaces: 256 ¦ IPv4 routes (static): 2048 ¦ IPv6 routes (static): 1024 ¦ Maximum host route table: 22528 ¦ ECMP entries: 768 ¦ IPv4 network router entries: 40960 ¦ IPv6 network router entries: 40960 ¦ Static ARP entries: 1024 ¦ Dynamic ARP: 45056 ¦ OSPF instances: 16 ¦ Multicast routes: 1000 ¦ IGMP multicast groups: 2048 ¦ VLAN groups: 4000 ¦ MAC VLAN address entries: 200 ¦ VLAN VPN (QinQ) entries: 256 ¦ MAC addresses per port: 64 ¦ IP MAC port binding entries: 1024 MAC Address Table Size: 128K entries Jumbo Frame Support: 9KB Routing Protocol: Static IP routing, OSPF, OSPFv2, OSPFv3, BGP, IS-IS, PIM-SM, PIM-DM, PIM-SSM, ECMP, policy-based routing (PBR), RIP-1, RIP-2, RIPng, IGMP, IGMPv2, IGMPv3, URPF, STP, MLD, L2PT, RIP, VRRPv2, VRRPv3, PPPoE, RSTP, MSTP, MLDv2 Remote Management Protocol: SFTP, NETCONF, CLI, SNMP 1, SNMP 2c, SNMP 3, IPv4, IPv6, DHCP, HTTPS, RMON 1, RMON 2, RMON 3, RMON 9, BOOTP, Telnet, TFTP, MIB, HTTP, RSTP Features: Aggregation mode, secure boot, 802.1x authentication, Port Security, image rollback, RSPAN, DAI, ERPS, ZTP, web-based management, security slot (Kensington security lock compatible), QoS, port priority, DSCP prioritization, WRR, bandwidth control, Voice VLAN, DSCP Marking, DHCP server, DHCPv4 relay, DHCPv6 relay, BFD, Link Aggregation, loopback detection, port mirroring, fast leave, IGMP snooping, MLD snooping, Multicast filtering function, MVR, DLDP support, DDM, sFlow, GVRP, port isolation, DoS, IPMB, AAA, store and forward, 15KV ESD Protector (air-gap discharge), 8KV ESD Protector (contact discharge), ACL support, VLAN Tagging, VLAN support, VPN support, Private VLAN, Broadcast Storm Control, Multicast Storm Control, Unknown Storm Control, Guest VLAN, MAB Compliant Standards: IEEE 802.1x, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ah, IEEE 802.1Q, IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad (LACP) Power: AC 100-240 V (50/60 Hz) Power Redundancy: Yes Dimensions (WxDxH): 17.3 in x 15 in x 1.7 in System Requirements: Microsoft Windows 98SE/2000/NT/XP/Vista/7/8/10, Apple MacOS, Linux, Microsoft Windows 11, Novell NetWare, UNIX - General
Device Type: Switch - 48 ports - L3 - managed - stackable Enclosure Type: Front to back airflow rack-mountable Subtype: 10 Gigabit Ethernet Ports: 48 x 10 Gigabit SFP+ + 4 x 100 Gigabit QSFP28 Performance: Switching capacity: 1760 Gbps ¦ Packet forwarding rate: 600 Mpps ¦ Stacking bandwidth: 800 Gbps ¦ Forwarding bandwidth: 880 Gbps Capacity: Buffer capacity (MB): 10 ¦ Priority queues: 8 ¦ Layer 3 IP interfaces: 256 ¦ IPv4 routes (static): 2048 ¦ IPv6 routes (static): 1024 ¦ Maximum host route table: 22528 ¦ ECMP entries: 768 ¦ IPv4 network router entries: 40960 ¦ IPv6 network router entries: 40960 ¦ Static ARP entries: 1024 ¦ Dynamic ARP: 45056 ¦ OSPF instances: 16 ¦ Multicast routes: 1000 ¦ IGMP multicast groups: 2048 ¦ VLAN groups: 4000 ¦ MAC VLAN address entries: 200 ¦ VLAN VPN (QinQ) entries: 256 ¦ MAC addresses per port: 64 ¦ IP MAC port binding entries: 1024 MAC Address Table Size: 128K entries Jumbo Frame Support: 9KB Max Units In A Stack: 12 Routing Protocol: Static IP routing, OSPF, OSPFv2, OSPFv3, BGP, IS-IS, PIM-SM, PIM-DM, PIM-SSM, ECMP, policy-based routing (PBR), RIP-1, RIP-2, RIPng, IGMP, IGMPv2, IGMPv3, URPF, STP, MLD, L2PT, RIP, VRRPv2, VRRPv3, PPPoE, RSTP, MSTP, MLDv2 Remote Management Protocol: SFTP, NETCONF, CLI, SNMP 1, SNMP 2c, SNMP 3, IPv4, IPv6, DHCP, HTTPS, RMON 1, RMON 2, RMON 3, RMON 9, BOOTP, Telnet, TFTP, MIB, HTTP, RSTP Encryption Algorithm: SSL 3.0, TLS 1.2 Authentication Method: RADSEC, Secure Shell (SSH), Secure Shell v.2 (SSH2), RADIUS, TACACS+ Features: Aggregation mode, secure boot, 802.1x authentication, Port Security, image rollback, RSPAN, DAI, ERPS, ZTP, web-based management, security slot (Kensington security lock compatible), QoS, port priority, DSCP prioritization, WRR, bandwidth control, Voice VLAN, DSCP Marking, DHCP server, DHCPv4 relay, DHCPv6 relay, BFD, Link Aggregation, loopback detection, port mirroring, fast leave, IGMP snooping, MLD snooping, Multicast filtering function, MVR, DLDP support, DDM, sFlow, GVRP, port isolation, DoS, IPMB, AAA, store and forward, 15KV ESD Protector (air-gap discharge), 8KV ESD Protector (contact discharge), ACL support, VLAN Tagging, VLAN support, VPN support, Private VLAN, Broadcast Storm Control, Multicast Storm Control, Unknown Storm Control, Guest VLAN, MAB Compliant Standards: IEEE 802.1x, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ah, IEEE 802.1Q, IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad (LACP) Processor: X ARM: 1.2 GHz RAM: 8 GB DDR4 SDRAM Flash Memory: 8 GB Built-in Devices: 4 x fans Status Indicators: Fan, system, power 1, power 2, management, stack, link/activity - Expansion / Connectivity
Interfaces: 48 x 1/10GBase-X SFP+ ¦ 4 x 40/100GBase-X QSFP28 ¦ 1 x console RJ-45 ¦ 1 x management (LAN) RJ-45 ¦ 1 x USB-C console ¦ 2 x USB 3.0 - Power
Power Device: Internal power supply - hot-plug Installed Qty: 1 Max Supported Qty: 2 Power Redundancy: Yes Power Redundancy Scheme: N+1 Voltage Required: AC 100-240 V (50/60 Hz) - Miscellaneous
Included Accessories: Rubber feet Cables Included: 1 x console cable Rack Mounting Kit: Included MTBF: 328,794 hours Compliant Standards: FCC, RoHS - Software / System Requirements
OS Required: Microsoft Windows 98SE/2000/NT/XP/Vista/7/8/10, Apple MacOS, Linux, Microsoft Windows 11, Novell NetWare, UNIX - Dimensions & Weight
Width: 17.3 in Depth: 15 in Height: 1.7 in - Environmental Parameters
Min Operating Temperature: 23 °F Max Operating Temperature: 122 °F Humidity Range Operating: 10 - 90% RH (non-condensing) Min Storage Temperature: -40 °F Max Storage Temperature: 158 °F Humidity Range Storage: 5 - 90% RH (non-condensing) - Special Feature
COO: Inquire TAA compliance: Inquire - UNSPSC Code
UNSPSC Code: 43222612
| BRANDS | TP-LINK |
|---|---|
| UNSPSC | 43222612 |
| Part# | TPL-S7500-48XF4C |
| MFG Part# | S7500-48XF4C |
| UPC | 840030711237 |
| Device Type | Switch - 48 ports - L3 - managed - stackable |
| Enclosure Type | Front to back airflow rack-mountable |
| Remote Management Protocol | BOOTP, CLI, DHCP, HTTP, HTTPS, IPv4, IPv6, MIB, NETCONF, RMON 1, RMON 2, RMON 3, RMON 9, RSTP, SFTP, SNMP 1, SNMP 2c, SNMP 3, Telnet, TFTP |
| Encryption Algorithm | SSL 3.0, TLS 1.2 |
