TRANSITION PS 48VDC 10A UNIV AC DIN 11803105
SKU
11803105
Category: Power Supplies
- Primary Information
Product Description: Transition Networks Hardened - power supply - 480 Watt Device Type: Power supply - DIN rail mountable Weight: 3.53 lbs Input Voltage: AC 115/230 V Output Voltage: DC 48 - 55 V ± 1% Power Capacity: 480 Watt Dimensions (WxDxH): 3.4 in x 5.1 in x 6 in Manufacturer Warranty: 5-year warranty - General
Device Type: Power supply - DIN rail mountable - Power Device
Input Voltage: AC 115/230 V Input Voltage Range: AC 90 - 264 / DC 127 - 370 V Frequency Required: 47 - 63 Hz Output Voltage: DC 48 - 55 V ± 1% Max Electric Current: 10 A Power Capacity: 480 Watt Efficiency: 94% - Miscellaneous
MTBF: 112.900 hours Features: Overheat protection, overvoltage protection, overload protection, short-circuit protection, convection cooling Compliant Standards: TUV, EN 61000-3-2, EN 61000-3-3, EN55024, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, EN 61000-4-5, EN 50082-2, EN 61000-6-2, EN 61000-4-11, RoHS, EN 61000-4-8, EN 60950-1, IEC 60068-2-6, UL 508, EN 55011, EN 61204-3, CISPR 32, EN 55032, EN 61204-3 Class B, SEMI F47, GL - Manufacturer Warranty
Service & Support: Limited warranty - 5 years - Environmental Parameters
Min Operating Temperature: -13 °F Max Operating Temperature: 158 °F Humidity Range Operating: 20 - 90% (non-condensing) - Dimensions & Weight
Width: 3.4 in Depth: 5.1 in Height: 6 in Weight: 3.53 lbs - Special Feature
COO: Inquire TAA compliance: Inquire - UNSPSC Code
UNSPSC Code: 39121004
| BRANDS | TRANSITION NETWORKS |
|---|---|
| UNSPSC | 39121004 |
| Part# | TNI-25160 |
| MFG Part# | 25160 |
| UPC | 648177042210 |
| Device Type | Power supply - DIN rail mountable |
| Efficiency | 94% |
