TRIPP DISPLAYPORT TO HDMI OVER CAT6 EXTENDER KIT WALL PLATE 4K 60 HZ 4/4/4 POC HDCP 22 230 FT 701 M TAA 6779435
SKU
6779435
- Primary Information
Product Description: Eaton Tripp Lite Series DisplayPort to HDMI over Cat6 Extender Kit, Wall Plate, 4K 60 Hz, 4:4:4, PoC, HDCP 2.2, 230 ft. (70.1 m), TAA - video/audio extender - HDMI, DisplayPort, 10Mb LAN - TAA Compliant Device Type: Video/audio extender Form Factor: In-wall / wall / rack mountable Localization: Australia, Europe, North America, United Kingdom Data Link Protocol: HDMI, DisplayPort, 10Mb LAN Max Transfer Distance: 230 ft Power Over Ethernet (PoE): PoC Power: AC 100-240 V TAA Compliant: Yes Manufacturer Warranty: 1-year warranty - General
Device Type: Video/audio extender Form Factor: In-wall / wall / rack mountable Color: White Localization: Australia, Europe, North America, United Kingdom - Networking
Connectivity Technology: Wired Data Link Protocol: HDMI, DisplayPort, 10Mb LAN Max Resolution: 3840 x 2160 @ 60 Hz Max Transfer Distance: 230 ft Status Indicators: Data Features: HDR support, 4K resolution support, 7.1 channel audio support, video mirror mode, 36-bit True Color support, 3D support, LPCM 5.1 support, LPCM 7.1 support, LPCM 2.0 support, 4:4:4 chroma subsampling support, dual display support Compliant Standards: HDCP 2.2, HDCP 1.4 - Expansion / Connectivity
Interfaces: 1 x DisplayPort (input) female ¦ 1 x HDMI (local unit) - Type A female ¦ 1 x HDMI (output) - Type A female ¦ 1 x network (receiver) - RJ-45 female ¦ 1 x network (transmitter) - RJ-45 female - Miscellaneous
Included Accessories: 4 power plug adapters, 4 x screws Mounting Kit: Included Compliant Standards: REACH, RoHS, FCC, CCC, GS, TUV, UL, cUL, DisplayPort 1.2a TAA Compliant: Yes - Power
Power Over Ethernet (PoE): PoC Power Device: External power adapter Voltage Required: AC 100-240 V (50/60 Hz) - Dimensions & Weight
Dimensions (WxDxH) / Weight Details: Transmitter: 2.8 in x 1.3 in x 4.5 in / 22.9 oz ¦ Receiver: 2.8 in x 1.3 in x 4.5 in / 22.9 oz - Manufacturer Warranty
Service & Support: Limited warranty - 1 year - Environmental Parameters
Min Operating Temperature: 32 °F Max Operating Temperature: 104 °F Humidity Range Operating: 0 - 85% (non-condensing) - Special Feature
COO: Inquire TAA compliance: Inquire - UNSPSC Code
UNSPSC Code: 43222608
| BRANDS | TRIPP LITE |
|---|---|
| UNSPSC | 43222608 |
| Part# | TRP-B127A-1A1-FDFH |
| MFG Part# | B127A-1A1-FDFH |
| UPC | 37332263957 |
| Max Transfer Distance | 230 ft |
| Max Resolution | 3840 x 2160 @ 60 Hz |
| Device Type | Video/audio extender |
| Connectivity Technology | Wired |
| Form Factor | In-wall / wall / rack mountable |
| Data Link Protocol | 10Mb LAN, DisplayPort, HDMI |
| Color | White |
