TRIPP LITE 3000VA2700W SMART LCD TOWER DB9 SNMP RT 5152134

Name: TRIPP LITE 3000VA2700W SMART LCD TOWER DB9 SNMP RT
Brand: TRIPP LITE
SKU: 5152134
Price: 5272.80 CAD
Availability: InStock

SKU

5152134

CA$5,272.80

Only 3 left

Tripp Lite series SmartOnline 3000VA 2700W 120V Double-Conversion UPS - 5 Outlets, Extended Run, Network Card Option, LCD, USB, DB9, Tower

Category: UPS

Primary Information

Product Description:	Tripp Lite SmartOnline - UPS - tower, extended run, double conversion - 2700 Watt - 3000 VA - VRLA
Device Type:	UPS - external
Weight:	73.63 lbs
Input Wiring:	1-phase
Input Voltage:	AC 120 V
Output Voltage:	AC 100/110/120 V
Power Capacity:	2700 Watt / 3000 VA
Input Connectors:	1 x power NEMA L5-30P
Output connectors:	4 x power NEMA 5-20R 20 A Â¦ 1 x power NEMA L5-30R 20 A
Battery:	Expandable valve regulated lead-acid (VRLA)
Run Time (Up To):	5.7 min at full load
Networking:	RS-232, USB
Dimensions (WxDxH):	8.4 in x 13.6 in x 16.2 in
Manufacturer Warranty:	2-year warranty

Power Device

UPS Technology:	On-line
Input Voltage:	AC 120 V
Input Voltage Range:	AC 100 - 127 V
Frequency Provided:	50/60 Hz
Input Wiring:	1-phase
Input Connectors:	1 x power NEMA L5-30P
Power Output Connectors Details:	4 x power NEMA 5-20R 20 A Â¦ 1 x power NEMA L5-30R 20 A
Output Voltage:	AC 100/110/120 V 50/60 Hz
Max Electric Current:	24 A
Power Capacity:	2700 Watt / 3000 VA
Output Waveform:	Sinewave
Surge Suppression:	Yes
Surge Energy Rating:	190 Joules
Circuit Protection:	Circuit breaker
Efficiency:	89% at 100% Load
Power Factor (PF):	0.99

Battery

Type:	Expandable
Technology:	Valve regulated lead-acid (VRLA)
Voltage Provided:	DC 96 V
Run Time (Up To):	5.7 min at full load Â¦ 16.7 min at half load
Recharge Time:	3 hours
Transfer Time:	0 ms
Features:	Sealed, hot-swappable

Expansion / Connectivity

Interfaces:	1 x battery detection Â¦ 1 x RS-232 - 9 pin D-Sub (DB-9) Â¦ 1 x relay output Â¦ 1 x RPO Â¦ 1 x USB - 4 pin USB Type B
Expansion Slots:	1 (total) / 1 (free) x expansion slot

Miscellaneous

Cables Included:	Power cable 8 ft Â¦ Serial cable - external Â¦ USB cable - external
Equipment Protection Value:	250000 US Dollars
Features:	VMware Ready, cisco compatible, EMI filtering, RFI filtering, on/off switch, metal housing, audible alarm, double conversion, controllable load banks, cooling fan, noise suppression, cold-start function, LED indicators, extended runtime, Auto Probe, auto reboot, LCD display
Compliant Standards:	RoHS, cUL, UL, REACH, FCC, NOM

Manufacturer Warranty

Service & Support: Limited warranty - 2 years
Environmental Parameters

Min Operating Temperature: 32 Â°F

Max Operating Temperature: 104 Â°F

Humidity Range Operating: 0 - 96% (non-condensing)

Sound Emission: 52 dB
Dimensions & Weight

Width: 8.4 in

Depth: 13.6 in

Height: 16.2 in

Weight: 73.63 lbs
Dimensions & Weight (Shipping)

Shipping Width: 12.6 in

Shipping Depth: 19.3 in

Shipping Height: 22.6 in

Shipping Weight: 82.01 lbs
Special Feature

COO: CHINA
UNSPSC Code

UNSPSC Code: 39121011
