TRIPP LITE EXTENDED RUN SNMP OPTION LCD USB DB9 5666884
SKU
5666884
CA$2,450.53
SmartOnline 208/230V 1kVA 900W Double-Conversion UPS, 2U, Extended Run, SNMP Card Option, LCD, USB, DB9, ENERGY STAR
Category: UPS
- Primary Information
Product Description: Eaton Tripp Lite Series SmartOnline 208/230V 1000VA 900W Double-Conversion UPS - 6 Outlets, Extended Run, Card Slot, LCD, USB, DB9, 2U Battery Backup - UPS - 900 Watt - 1000 VA Device Type: UPS - rack-mountable Rack Size: 19" - 2U Weight: 28 lbs Input Wiring: 1-phase Input Voltage: AC 200/208/220/230/240 V Output Voltage: AC 200/208/220/230/240 V ± 2% Power Capacity: 900 Watt / 1000 VA Input Connectors: 1 x power IEC 60320 C14 Output connectors: 6 x power IEC 60320 C13 Battery: Expandable Run Time (Up To): 4.7 min at full load Networking: RS-232, USB Dimensions (WxDxH): 17.2 in x 15.6 in x 3.5 in Manufacturer Warranty: 2-year warranty - General
Device Type: UPS - rack-mountable Height (Rack Units): 2U Rack Size: 19" - Power Device
UPS Technology: On-line Input Voltage: AC 200/208/220/230/240 V Frequency Provided: 50/60 Hz Input Wiring: 1-phase Frequency Required: 50/60 Hz Input Connectors: 1 x power IEC 60320 C14 Power Output Connectors Details: 6 x power IEC 60320 C13 Output Voltage: AC 200/208/220/230/240 V ± 2% - 50/60 Hz Power Capacity: 900 Watt / 1000 VA Output Waveform: Sinewave Surge Suppression: Yes Surge Energy Rating: 627 Joules Efficiency: 96% Power Factor (PF): 0.9 - Battery
Type: Expandable Voltage Provided: 24 V Run Time (Up To): 4.7 min at full load ¦ 12.3 min at half load - Networking
Remote Management Interface: RS-232, USB - Expansion / Connectivity
Interfaces: 1 x EPO (emergency power off) ¦ 1 x USB ¦ 1 x RS-232 - 9 pin D-Sub (DB-9) Expansion Slots: 1 (total) / 1 (free) x expansion slot - Miscellaneous
Cables Included: 2 x power cable - external ¦ Serial cable - external ¦ USB cable - external Rack Mounting Kit: Included Equipment Protection Value: 250000 US Dollars Features: Built-in cooling fan, audible alarm, LCD display, LED indicators, overvoltage protection, undervoltage protection, cold-start function, cooling fan, hot-swappable batteries, Energy-Saving Outlets Compliant Standards: CSA, EAC, SASO, UL 1778, FCC Class A certified, IEC 62040-1:2008+A1, EN 62040-2 - Manufacturer Warranty
Service & Support: Limited warranty - 2 years - Environmental Parameters
Min Operating Temperature: 32 °F Max Operating Temperature: 104 °F Humidity Range Operating: 5 - 95% (non-condensing) Sound Emission: 45 dB - Dimensions & Weight
Width: 17.2 in Depth: 15.6 in Height: 3.5 in Weight: 28 lbs - Dimensions & Weight (Shipping)
Shipping Width: 20 in Shipping Depth: 24 in Shipping Height: 9.5 in - Special Feature
COO: Inquire TAA compliance: Inquire - UNSPSC Code
UNSPSC Code: 39121011
| BRANDS | TRIPP LITE |
|---|---|
| UNSPSC | 39121011 |
| Part# | TRP-SUINT1000LCD2U |
| MFG Part# | SUINT1000LCD2U |
| UPC | 37332185648 |
| Device Type | UPS - rack-mountable |
| UPS Technology | On-line |
| Surge Suppression | Yes |
| Type | Expandable |
| Efficiency | 96% |
