TRIPP LITE UPS SMART TOWER DESKTOP AVR LCD 1440VA 6425498
SKU
6425498
CA$856.44
SMART1500TSU - UPS - Tower - line-interactive - 1200Watt - 1440VA - 15A - 8x NEMA 5-15R - 2-year warranty, 3 year with registration.
Category: UPS
- Primary Information
Product Description: Tripp Lite 1440VA 1200W UPS Smart Tower Battery Back Up Desktop AVR USB LCD - UPS - 1200 Watt - 1440 VA Device Type: UPS - external Weight: 32.21 lbs Input Wiring: 1-phase Input Voltage: AC 120 V Output Voltage: AC 120 V + 6% / - 12% Power Capacity: 1200 Watt / 1440 VA Input Connectors: 1 x power NEMA 5-15P Output connectors: 6 x power NEMA 5-15R (UPS and surge) ¦ 2 x power NEMA 5-15R (surge) Run Time (Up To): 2 min at full load Networking: RS-232, USB Dimensions (WxDxH): 5.5 in x 15 in x 7.5 in - General
Device Type: UPS - external - Power Device
UPS Technology: Line interactive Input Voltage: AC 120 V Frequency Provided: 50/60 Hz Input Wiring: 1-phase Input Connectors: 1 x power NEMA 5-15P Power Output Connectors Details: 6 x power NEMA 5-15R (UPS and surge) ¦ 2 x power NEMA 5-15R (surge) Output Voltage: AC 120 V + 6% / - 12% - 50/60 Hz Max Electric Current: 12 A Power Capacity: 1200 Watt / 1440 VA Dataline Surge Protection: Network/phone line - 1 input line / 1 output line Output Waveform: Sinewave Surge Suppression: Yes Surge Energy Rating: 316 Joules Circuit Protection: Circuit breaker Efficiency: 95% Power Factor (PF): 0.83 - Battery
Run Time (Up To): 2 min at full load ¦ 8 min at half load Recharge Time: 8 hours Transfer Time: 6 ms - Networking
Remote Management Interface: RS-232, USB - Expansion / Connectivity
Interfaces: 1 x management (RS-232) - 9 pin D-Sub (DB-9) ¦ 1 x management (USB) - 4 pin USB Type B - Miscellaneous
Cables Included: Power cable - integrated - 5 ft ¦ USB cable - external ¦ RS-232 cable - external Equipment Protection Value: 250000 US Dollars Features: LCD display, Automatic Voltage Regulation (AVR), overvoltage protection, noise filtering, undervoltage protection, audible alarm, cold-start function, overload protection, cooling fan Compliant Standards: FCC Part 15 A, EMI, CSA, NOM, UL 1778, CAN/CSA C22.2 No. 107.3:2014 3rd Edition, FCC Part 68, FCC Class A certified, RoHS - Environmental Parameters
Min Operating Temperature: 32 °F Max Operating Temperature: 104 °F Humidity Range Operating: 0 - 90% (non-condensing) - Dimensions & Weight
Width: 5.5 in Depth: 15 in Height: 7.5 in Weight: 32.21 lbs - Special Feature
COO: Inquire TAA compliance: Inquire - UNSPSC Code
UNSPSC Code: 39121011
| BRANDS | TRIPP LITE |
|---|---|
| UNSPSC | 39121011 |
| Part# | TRP-SMART1500TSU |
| MFG Part# | SMART1500TSU |
| UPC | 37332214249 |
| Device Type | UPS - external |
| UPS Technology | Line interactive |
| Surge Suppression | Yes |
| Efficiency | 95% |
| Circuit Protection | Circuit breaker |
