TRIPPLITE SUINT1500LCD1U 7243444
SKU
7243444
- Primary Information
Product Description: Eaton Tripp Lite Series SmartOnline 1500VA 1440W 208/230V Double-Conversion UPS - 5 Outlets, Network Card Option, LCD, USB, DB9, 1U Rack Battery Backup - UPS - 1440 Watt - 1500 VA - VRLA Device Type: UPS - rack-mountable Rack Size: 19" - 2U Weight: 45.19 lbs Input Wiring: 1-phase Input Voltage: AC 200/208/220/230/240 V Output Voltage: AC 200/208/220/230/240 V Power Capacity: 1440 Watt / 1500 VA Input Connectors: 1 x power IEC 60320 C14 Output connectors: 6 x power IEC 60320 C13 (UPS and surge) Battery: Lead acid expandable valve regulated lead-acid (VRLA) Run Time (Up To): 3 min at full load Networking: RS-232, USB Dimensions (WxDxH): 17.3 in x 27.9 in x 1.7 in Manufacturer Warranty: 2-year warranty - General
Device Type: UPS - rack-mountable Height (Rack Units): 2U Rack Size: 19" - Power Device
UPS Technology: On-line Input Voltage: AC 200/208/220/230/240 V Frequency Provided: 50/60 Hz Input Wiring: 1-phase Frequency Required: 50/60 Hz Input Connectors: 1 x power IEC 60320 C14 Power Output Connectors Details: 6 x power IEC 60320 C13 (UPS and surge) Output Voltage: AC 200/208/220/230/240 V 50/60 Hz Power Capacity: 1440 Watt / 1500 VA Output Waveform: Sinewave Surge Suppression: Yes Surge Energy Rating: 540 Joules Efficiency: 89% at 100% Load Power Factor (PF): 0.96 Total Harmonic Distortion (THD): 8 % - Battery
Type: Expandable Technology: Valve regulated lead-acid (VRLA) lead acid Voltage Provided: 48 V Run Time (Up To): 3 min at full load ¦ 10 min at half load Transfer Time: 0 ms - Networking
Remote Management Interface: RS-232, USB - Expansion / Connectivity
Interfaces: 1 x management (USB) - 4 pin USB Type B ¦ 1 x management (RS-232) - 9 pin D-Sub (DB-9) ¦ 1 x EPO (emergency power off) - RJ-11 Expansion Slots: 1 (total) / 1 (free) x expansion slot - Miscellaneous
Cables Included: 2 x power cable - external - 6 ft ¦ Serial cable - external ¦ USB cable - external Rack Mounting Kit: Included Equipment Protection Value: 250000 US Dollars Features: EMI filtering, RFI filtering, steel housing, double conversion, LCD display, black-out protection, brown-out protection, transient surge protection, zero transfer time, LED indicators, cooling fan, energy saving green topology, cold-start function, crest factor meter, overvoltage protection, hot-swappable batteries, 4 switchable sockets, Energy-Saving Outlets, audible alarm, noise suppression Compliant Standards: CSA, ICES, UL 1778, FCC Part 15 A, RoHS - Manufacturer Warranty
Service & Support: Limited warranty - 2 years - Environmental Parameters
Min Operating Temperature: 32 °F Max Operating Temperature: 104 °F Humidity Range Operating: 0 - 95% (non-condensing) Sound Emission: 65 dBA - Dimensions & Weight
Width: 17.3 in Depth: 27.9 in Height: 1.7 in Weight: 45.19 lbs - Dimensions & Weight (Shipping)
Shipping Width: 22.8 in Shipping Depth: 32.7 in Shipping Height: 6.1 in Shipping Weight: 52.91 lbs - Special Feature
COO: Inquire TAA compliance: Inquire - UNSPSC Code
UNSPSC Code: 39121000
| BRANDS | TRIPP LITE |
|---|---|
| UNSPSC | 39121000 |
| Part# | TRP-SUINT1500LCD1U |
| MFG Part# | SUINT1500LCD1U |
| Device Type | UPS - rack-mountable |
| UPS Technology | On-line |
| Surge Suppression | Yes |
| Type | Expandable |
| Efficiency | 89% at 100% Load |
