TRIPPLITE UPS SMART 3000W 120V AVR LCD USB 2U TAA 8045855
SKU
8045855
CA$3,954.60
TAA COMPLIANT SMARTPRO 3000VA 3000W 120V LINE-INTERACTIVE SINE WAVE UPS - 7 OUTLETS, EXTENDED RUN, NETWORK CARD OPTION, LCD, USB, DB9, 2U RACK/TOWER
Category: UPS
- Primary Information
Product Description: Eaton Tripp Lite Series 3000VA 3000W 120V Line-Interactive Sine Wave UPS - 7 Outlets, Extended Run, Network Card Option, LCD, USB, DB9, 2U Rack/Tower, TAA - UPS - 3000 Watt - 3000 VA - TAA Compliant Device Type: UPS - external Rack Size: 19" - 2U Weight: 74.49 lbs Input Voltage: AC 120 V Output Voltage: AC 120 V + 15% / - 13% Power Capacity: 3000 Watt / 3000 VA Input Connectors: 1 x power NEMA L5-30P Output connectors: 6 x power NEMA 5-20R ¦ 1 x power NEMA L5-30R Battery: Expandable Run Time (Up To): 3 min at full load Networking: USB, RS-232 Remote Management Protocol: SNMP Included Accessories: Tower support stands TAA Compliant: TAA Compliant Dimensions (WxDxH): 17.2 in x 23.7 in x 3.4 in Environmental Standards: ENERGY STAR Manufacturer Warranty: 3-year warranty with product registration - General
Device Type: UPS - external Height (Rack Units): 2U Rack Size: 19" - Power Device
UPS Technology: Line interactive Input Voltage: AC 120 V Frequency Provided: 50/60 Hz Frequency Required: 50/60 Hz Input Connectors: 1 x power NEMA L5-30P Power Output Connectors Details: 6 x power NEMA 5-20R ¦ 1 x power NEMA L5-30R Output Voltage: AC 120 V + 15% / - 13% - 50/60 Hz Power Capacity: 3000 Watt / 3000 VA Output Waveform: Sinewave Surge Suppression: Yes Surge Energy Rating: 380 Joules Efficiency: 96% at 100% Load Power Factor (PF): 1.0 - Battery
Type: Expandable Voltage Provided: DC 72 V Run Time (Up To): 3 min at full load ¦ 9 min at half load Recharge Time: 5 hours Transfer Time: 4 ms Features: Valve-regulated - Networking
Remote Management Interface: USB, RS-232 Remote Management Protocol: SNMP - Expansion / Connectivity
Interfaces: 1 x management (USB) - 4 pin USB Type B ¦ 1 x management (RS-232) - 9 pin D-Sub (DB-9) ¦ 1 x EPO (emergency power off) ¦ 1 x RPO/ROO ¦ 1 x battery detection - RJ-45 Expansion Slots: 1 (total) / 1 (free) x expansion slot - Miscellaneous
Included Accessories: Tower support stands Cables Included: Power cable - integrated - 10 ft ¦ USB cable - external ¦ Serial cable - external Rack Mounting Kit: Included Equipment Protection Value: 250000 US Dollars Features: Metal housing, black-out protection, brown-out protection, Automatic Voltage Regulation (AVR), pure sinewave output, controllable load banks, audible alarm, LED indicators, LCD display, cooling fan, cold-start function, energy saving green topology, noise filtering, overvoltage protection, undervoltage protection, hot-swappable batteries Compliant Standards: CSA, ICES, NOM, UL 1778, FCC Part 15 Class B, RoHS TAA Compliant: Yes - Software / System Requirements
Software Included: TrippLite PowerAlert - Sustainability Information
ENERGY STAR: Yes - Manufacturer Warranty
Service & Support: Limited warranty - 3 years with product registration - Environmental Parameters
Min Operating Temperature: 32 °F Max Operating Temperature: 104 °F Humidity Range Operating: 20 - 95% RH (non-condensing) Sound Emission: 50 dBA - Dimensions & Weight
Width: 17.2 in Depth: 23.7 in Height: 3.4 in Weight: 74.49 lbs - Dimensions & Weight (Shipping)
Shipping Width: 22.8 in Shipping Depth: 30.9 in Shipping Height: 9.4 in Shipping Weight: 87.7 lbs - Special Feature
COO: TAIWAN - UNSPSC Code
UNSPSC Code: 39121011
| BRANDS | TRIPP LITE |
|---|---|
| UNSPSC | 39121011 |
| Part# | TRP-SMART3000RXLTAA |
| MFG Part# | SMART3000RXLTAA |
| UPC | 786689816070 |
| Device Type | UPS - external |
| UPS Technology | Line interactive |
| Surge Suppression | Yes |
| Type | Expandable |
| Efficiency | 96% at 100% Load |
| Remote Management Protocol | SNMP |
