CATALYST 1300 12-PORT SFP+, 2X10GE SHARED 7978096
SKU
7978096
CA$2,138.51
Wired Switch C1300-12XS,1RU,16K MAC,support SNMP,DHCP,HTTP,TFTP,Layer 2/3,RADIUS, TACACS+,802.1s,802.1w,802.1d, 802.1x,Power supply,12x 10 Gigabit Ethernet; USB,Flash 512 MB ,ARM dual-core,1 GB DDR4,MTBF 2165105 hours,Limited lifetime
Category: Hubs & Switches
- Primary Information
Network Device Type: Switch Model: C1300-12XS Form Factor: Rack-Mountable Connectivity Technology: Wired Data Transfer Rate: 10 Gbps Data Link Protocol: Gigabit Ethernet Status Indicators: LED Indicators Processor / Type: ARM RAM / Total Installed Size: 1 GB Flash Memory / Installed Size: 512 MB Networking Compliant Standards: IEEE 802.1s,802.1w,802.1d, 802.1x Power / Device Type: Power Supply Media Layer Supported: Layer 2 and Layer 3 Power / Voltage Required: 100-240V 50-60 Hz MTBF: 2165105 hours Features: The Cisco Network Plug and Play solution provides a simple, secure, unified, and integrated offering to ease new device rollouts or for provisioning updates to an existing network. The intuitive user interfaces reduce the time required to deploy, troubleshoot, and manage the network and allow you to support sophisticated capabilities without increasing IT head count. Support for Simple Network Management Protocol (SNMP) allows you to set up and manage your switches and other Cisco devices remotely from a network management station, improving IT workflow and mass configurations. - Network
Power Over Ethernet (PoE) Support: none PoE Power Consumption: none MAC Address Table Size: 16000 Jumbo Frame Support: up to 9000 bytes Remote Management Protocol: DHCP; Syslog; SNMP; HTTPS; TFTP; HTTP; SSH Routing Protocol: IPv4 ,IPv6,CIDR Encryption Algorithm: SSL Authentication Method: RADIUS, TACACS+ Interfaces: 12x 10 Gigabit Ethernet; USB - Interfaces / Ports
Interfaces: 12x 10 Gigabit Ethernet; USB - Dimensions&Miscellaneous
Width: 10.56 Inch Depth: 10.69 Inch Height: 1.73 Inch Weight: 2.49 Kg - Service&Support
Service & Support Type: Limited lifetime with return-to-factory replacement - Special Feature
Min Operating Temperature: -5 Celsius Max Operating Temperature: 50 Celsius Min Storage Temperature: -25 Celsius Max Storage Temperature: 70 Celsius COO: Inquire TAA compliance: Inquire - UNSPSC Code
UNSPSC Code: 43222612
| BRANDS | CISCO SYSTEMS |
|---|---|
| UNSPSC | 43222612 |
| Part# | CSC-C1300-12XS |
| MFG Part# | C1300-12XS |
| UPC | 889728521598 |
| Flash Memory / Installed Size | 512 MB |
| Network Device Type | Switch |
| RAM / Total Installed Size | 1 GB |
| Connectivity Technology | Wired |
| Data Transfer Rate | 10 Gbps |
| Form Factor | Rack-Mountable |
| Processor / Type | ARM |
| Data Link Protocol | Gigabit Ethernet |
| Power / Device Type | Power Supply |
| Remote Management Protocol | DHCP, HTTP, HTTPS, SNMP, SSH, Syslog, TFTP |
| Encryption Algorithm | SSL |
