MSI MEG Z790 MONSTER HUNTER EDITION GAMING MOTHERBOARD 7996782
SKU
7996782
Category: Motherboards
- Primary Information
Product Description: MSI MPG Z790 Edge - Monster Hunter Edition - motherboard - ATX - LGA1700 Socket - Z790 Product Type: Motherboard - ATX Chipset Type: Intel Z790 Processor Socket: 1 x LGA1700 Socket Compatible Processors: (supports 12th/13th and 14th Generation Intel Core / Pentium Gold / Celeron) Max RAM Size: 192 GB RAM Supported: 4 DIMM slots - DDR5, non-ECC, unbuffered Storage Ports: 8 x SATA-600 (RAID), 5 x M.2 USB / FireWire Ports: 1 x USB-C 3.2 Gen 2x2 + 1 x USB-C 3.2 Gen 2 + 4 x USB 3.2 Gen 2 + 4 x USB 3.2 Gen 1 + (1 x USB-C 3.2 Gen 2 + 2 x USB 3.2 Gen 1 + 4 x USB 2.0 via headers) Audio: HD Audio (8-channel) LAN: 2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax/be (Wi-Fi 7), Bluetooth 5.4 - General
Product Type: Motherboard - ATX Chipset Type: Intel Z790 Processor Socket: LGA1700 Socket Max Processors Qty: 1 Compatible Processors: (supports 12th/13th and 14th Generation Intel Core / Pentium Gold / Celeron) - Supported RAM
Max Size: 192 GB Technology: DDR5 Bus Clock: 5800 MHz (O.C.), 6000 MHz (O.C.), 4800 MHz, 6200 MHz (O.C.), 6400 MHz (O.C.), 6600 MHz (O.C.), 7000 MHz (O.C.), 6800 MHz (O.C.), 7200 MHz (O.C.), 5200 MHz, 5000 MHz, 5600 MHz, 5400 MHz, 7400 MHz (O.C.), 7600 MHz (O.C.), 7800 MHz (O.C.) Supported RAM Integrity Check: Non-ECC Registered or Buffered: Unbuffered Features: Dual channel memory architecture, Intel Extreme Memory Profiles (XMP) 3.0 - Audio
Type: HD Audio (8-channel) Audio Codec: Realtek ALC4080 Compliant Standards: High Definition Audio - LAN
Network Interfaces: 2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax/be (Wi-Fi 7), Bluetooth 5.4 - Expansion / Connectivity
Expansion Slots: 1 x CPU ¦ 4 x DIMM 288-pin ¦ 1 x PCIe 5.0 x16 ¦ 1 x PCIe 4.0 x16 (x4 mode) ¦ 1 x PCIe 3.0 x1 ¦ 2 x M.2 socket (2260/2280 M.2 Key M slot) ¦ 1 x M.2 socket (2260/2280/22110 M.2 Key M slot) ¦ 2 x M.2 socket (2242/2260/2280 M.2 Key M slot) ¦ 1 x M.2 socket (Key E) Storage Interfaces: SATA-600 -connectors: 8 x 7pin Serial ATA ¦ SATA-600 / PCIe 4.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5 ¦ PCIe 4.0 -connectors: 3 x M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5 ¦ PCIe 5.0 -connectors: 1 x M.2 Interfaces: 1 x HDMI ¦ 1 x DisplayPort ¦ 4 x USB 3.2 Gen 1 ¦ 4 x USB 3.2 Gen 2 ¦ 1 x USB-C 3.2 Gen 2 ¦ 1 x USB-C 3.2 Gen2x2 ¦ 1 x audio line-out - mini-jack ¦ 1 x microphone - mini-jack ¦ 1 x audio line-out (center/subwoofer) - mini-jack ¦ 1 x audio line-out (rear) - mini-jack ¦ 1 x audio line-in - mini-jack ¦ 1 x SPDIF out ¦ 2 x antenna ¦ 1 x LAN (2.5Gigabit Ethernet) Internal Interfaces: 4 x USB 2.0 - header ¦ 2 x USB 3.2 Gen 1 - header ¦ 1 x USB-C 3.2 Gen 2 - header ¦ 1 x audio - header ¦ 1 x Thunderbolt - header ¦ 1 x SPI - header Power Connectors: 24-pin main power connector, 2 x 8-pin ATX12V connectors - Features
Hardware Features: Clear CMOS Button, Debug LED, 6 Layer PCB, MSI Mystic Light, MSI Steel Armor, 2oz Copper PCB, M.2 Shield FROZR, Water Pump Header, pre-mounted I/O shield, MSI Core Boost, Extended Heatsink Design, DIY Friendly Design, EZ LED control, 90A Smart Power Stage, 16+1+1 Phase Power Design, MSI Audio Boost 5, Surface Mount Technology (SMT), Smart Power Stage (SPS) technology, MSI Memory Boost, Enlarged Chipset Heatsink, Direct Touch Heat-pipe, flash BIOS button - Miscellaneous
Included Accessories: USB drive, Wi-Fi antenna, 3 x M.2 clips, cable sticker Cables Included: 2 x Serial ATA cable Software Included: AIDA64 Extreme (60 days trial), MSI Center, Norton 360 Deluxe (60 days trial) Compliant Standards: BSMI, RoHS, WEEE, FIPS, FISMA, FCC Part 15 Class B, JIS C 0950, DisplayPort 1.4 Width: 12 in Depth: 9.6 in - Special Feature
COO: Inquire TAA compliance: Inquire - UNSPSC Code
UNSPSC Code: 43201513
| BRANDS | MSI COMPUTER (USA) |
|---|---|
| UNSPSC | 43201513 |
| Part# | MSI-Z790MONSTER |
| MFG Part# | Z790MONSTER |
| UPC | 824142358986 |
| Product Type | Motherboard - ATX |
| Type | HD Audio (8-channel) |
