SMARTEYES 8MP BULLET IP CAMERA WITH ACUSENSE 7293436
SKU
7293436
CA$208.80
NC328G2-XB-6 - IP Bullet Camera - CMOS - 8MP - 6 mm - 20Frames per second - 256GB
Category: PC & Network Cameras
- Primary Information
Product Description: Galaxy Platinum NC328G2-XB-6 - network surveillance camera - bullet Device Type: Network surveillance camera - fixed - bullet - dust resistant / water resistant Dimensions (WxDxH): 4.1 in x 11.5 in x 4.1 in Weight: 2.4 lbs Connectivity Technology: Wired Camera: Color - Day&Night Max Resolution: 3840 x 2160 Frame Rate (max): 30 frames per second Motion Detection: Yes Video Modes: 1080p, 2160p, 720p, 360p Optical Sensor Type: Progressive Scan CMOS - 1/2.8" - 8 MP Minimum Illumination: 0.005 lux - color - F1.6 - AGC on ¦ 0 lux - IR Focal Length Control: Fixed focal Focal Length: 6 mm Lens Mounting: M12 mount Focus Adjustment: Fixed focus Lens Iris: F/1.6 - fixed iris Panning Range (degree): 0 to 360 Tilting Range (degree): 0 to 90 Interfaces: Ethernet 10Base-T/100Base-TX Voltage: DC 12 V / PoE Features: Wide Dynamic Range (WDR), face detection, intrusion detection, tripwire detection, Vehicle Detection, human detection, slow shutter, ICR filter, manual 360° rotation, smart supplement light, Constant Bitrate (CBR), Variable Bitrate (VBR), Region of Interest (ROI), ONVIF (Profile G) support, ONVIF (Profile S) support, password protection, 802.1x authentication, complicated password, HTTPs encryption, IP address filtering, security audit log, digest authentication, WSSE, NAS-Ready, Automatic Network Replenishment (ANR), image mirror, Privacy Mask Function, saturation control, brightness control, Backlight Compensation (BLC), Highlight Compensation (HLC), 3D digital noise reduction (DNR), contrast control, sharpness control, Gain Control, white balance, digital image rotation, reset button, aluminum housing, anti-flicker, heartbeat, Line Crossing Detection, Pixel Counter Support, password reset via e-mail Environmental Parameters (operating): -22 °F - 140 °F; 0 - 95% (non-condensing) relative humidity - General
Device Type: Network surveillance camera Form Factor: Bullet Connectivity Technology: Wired Width: 4.1 in Depth: 11.5 in Height: 4.1 in Weight: 2.4 lbs - Camera
Type: Color - Day&Night - fixed - dust resistant / water resistant Digital Video Format: H.265+, H.264+, H.264, H.265, MJPEG Max Digital Video Resolution: 3840 x 2160 Motion Detection: Yes Video Modes: 1080p, 2160p, 720p, 360p Exposure Range: 1/3 sec - 1/100000 sec Minimum Illumination: 0.005 lux - color - F1.6 - AGC on ¦ 0 lux - IR Infrared LEDs: Yes Infrared Distance: 197 ft Digital Video Capture Resolution: 3840 x 2160, 3200 x 1800, 2688 x 1520, 1920 x 1080, 1280 x 720, 640 x 480, 640 x 360 Frame Rate (max): 30 frames per second Features: Wide Dynamic Range (WDR), face detection, intrusion detection, tripwire detection, Vehicle Detection, human detection, slow shutter, ICR filter, manual 360° rotation, smart supplement light, Constant Bitrate (CBR), Variable Bitrate (VBR), Region of Interest (ROI), ONVIF (Profile G) support, ONVIF (Profile S) support, password protection, 802.1x authentication, complicated password, HTTPs encryption, IP address filtering, security audit log, digest authentication, WSSE, NAS-Ready, Automatic Network Replenishment (ANR), image mirror, Privacy Mask Function, saturation control, brightness control, Backlight Compensation (BLC), Highlight Compensation (HLC), 3D digital noise reduction (DNR), contrast control, sharpness control, Gain Control, white balance, digital image rotation, reset button, aluminum housing, anti-flicker, heartbeat, Line Crossing Detection, Pixel Counter Support, password reset via e-mail - Image Sensor
Type: 8 MP Progressive Scan CMOS 1/2.8" - Lens Construction
Type: M12 mount - fixed focal Focal Length: 6 mm Lens Iris: F/1.6 fixed iris Focus Adjustment: Fixed focus - Panning
Range (degree): 0 to 360 - Tilting
Range (degree): 0 to 90 - Interfaces
Network Interface: Ethernet 10Base-T/100Base-TX Network Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, QOS, IPv6, IPv4, UDP, Bonjour, SSL, TLS, PPPoE, SNMP, SMB, CIFS - Expansion / Connectivity
Ports: LAN/power - RJ-45 Supported Memory Cards: microSD Card Encryption Algorithm: TLS 1.1, TLS 1.2 - Miscellaneous
Compliant Standards: IEC 60529 IP67, IEEE 802.3af Class 3, FCC 47 CFR Part 15 Subpart B, EN 55032:2015, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 50130-4:2011+A1:2014, RCM, EMC, AS/NZS CISPR 32:2015, ICES-003 issue 6, IC, KC, KN32:2015, KN35:2015, UL 60950-1, CB, IEC 60950-1:2005 + Am1:2009 + Am2:2013, LVD, EN 60950-1:2005+Am1:2009+Am 2:2013, REACH 1907/2006/CE, RoHS 2011/65/EU, WEEE 2012/19/EU - Power
Power Requirements: DC 12 V / PoE - Dimensions & Weight (Shipping)
Shipping Width: 6.1 in Shipping Depth: 15.2 in Shipping Height: 6.1 in Shipping Weight: 3.51 lbs - Environmental Parameters
Min Operating Temperature: -22 °F Max Operating Temperature: 140 °F Relative Humidity (operating): 0 - 95% (non-condensing) - Special Feature
COO: Inquire TAA compliance: Inquire - UNSPSC Code
UNSPSC Code: 46171610
| BRANDS | GALAXY SECURITY |
|---|---|
| UNSPSC | 46171610 |
| Part# | SMR-NC328G2-XB-6 |
| MFG Part# | NC328G2-XB-6 |
| Max Resolution | 3840 x 2160 |
| Device Type | Network surveillance camera |
| Connectivity Technology | Wired |
| Form Factor | Bullet |
| Type | M12 mount - fixed focal |
| Focus Adjustment | Fixed focus |
| Digital Video Format | H.264, H.264+, H.265, H.265+, MJPEG |
| Digital Video Capture Resolution | 1280 x 720, 1920 x 1080, 2688 x 1520, 3200 x 1800, 3840 x 2160, 640 x 360, 640 x 480 |
| Focal Length | 6 mm |
| Encryption Algorithm | TLS 1.1, TLS 1.2 |
