TRENDNET 52-PORT GIGABIT WEB SMART POE+ SWITCH WITH 10G SFP+ SLOTS 7244796
SKU
7244796
CA$1,219.11
Category: Hubs & Switches
- Primary Information
Network Device Type: Switch Model: TPE-3524S Data Transfer Rate: 10 Gbps Networking / Ports Qty: 53 Data Link Protocol: Gigabit Ethernet VLAN IP interfaces: 802.1Q Tagged VLAN Dynamic GVRP Up to 256 VLAN groups, ID Range 1-4094 Private VLAN (Protected Ports) Voice VLAN (10 user defined OUIs) Status Indicators: LED indicators RAM / Total Installed Size: 2 MB Power / Device Type: Power Supply Max Power Consumption: 57.4 Watt Power / Voltage Required: Input: 100 - 240V AC, 50/60Hz MTBF: 37300 hours Features: 48 x Gigabit PoE+ ports 4 x 10G SFP+ ports 410W PoE power budget Easy-to-use web-based management interface Supports IPv6, LACP, VLAN, QoS, and IGMP/MLD Snooping IPv4/IPv6 Static Routing support Bandwidth control per port Private, Multicast, and Voice VLAN support Smart fans 176Gbps switching capacity IEEE 802.1p QoS with queue scheduling support NDAA / TAA compliant (U.S. and Canada only) Lifetime Warranty - Network
PoE Power Consumption: 410W MAC Address Table Size: 32K entries Jumbo Frame Support: 9KB Routing Protocol: IPv4/IPv6 Static Routing support SFP+ Ports: 4 Interfaces: 48 x Gigabit PoE+ ports; 4 x 10G SFP+ ports; - Interfaces / Ports
Interfaces: 48 x Gigabit PoE+ ports; 4 x 10G SFP+ ports; VLAN IP interfaces: 802.1Q Tagged VLAN Dynamic GVRP Up to 256 VLAN groups, ID Range 1-4094 Private VLAN (Protected Ports) Voice VLAN (10 user defined OUIs) SFP+ Ports: 4 - Dimensions&Miscellaneous
What's Included: TPE-3524S Quick Installation Guide Power cord (1.5m / 5 ft.) Console cable (1m / 3.28ft.) Rackmount brackets Width: 17.32 Inch Depth: 12.2 Inch Height: 1.73 Inch Weight: 4.75 Kg - Service&Support
Service & Support Type: Lifetime Warranty - Special Feature
Min Operating Temperature: 0 degree Max Operating Temperature: 50 degree COO: Inquire TAA compliance: Inquire - UNSPSC Code
UNSPSC Code: 43222612
| BRANDS | TRENDNET |
|---|---|
| UNSPSC | 43222612 |
| Part# | TEI-TPE-3524S |
| MFG Part# | TPE-3524S |
| UPC | 710931162509 |
| Network Device Type | Switch |
| RAM / Total Installed Size | 2 MB |
| Data Transfer Rate | 10 Gbps |
| Networking / Ports Qty | 53 |
| Data Link Protocol | Gigabit Ethernet |
| Power / Device Type | Power Supply |
